- 28 -
Only
We recommend that all of the blades are changed at the same time. The
trowel may wobble or bounce if not.
13.5.1 Place the machine on a flat, level surface. Adjust the blade pitch
control to make the blades as flat as possible.
NOTE
Pay attention to the blade orientation on the trowel arm.
13.5.2 Remove the two bolts and lock the washers that secure the blade to
the trowel arm.
13.5.3 Remove the blade.
13.5.4 Using a wire brush, scrape all concrete particles and forgein debris
from the trowel arm.
13.5.5 Install the new trowel blade onto the trowel arm. Make sure the
blade is installed correctly, maintaining the proper orientation for direction
of rotation.
13.5.6 Reinstall the two bolts and lock washers that secure the blade to the
trowel arm. Tighten the bolts securely.
13.5.7 Repeat steps for all remaining blades.
13.6 Installing Pans onto Finisher Blades
WARNING
Lifting/Crush Hazard.
Do NOT lift the trowel with the pans attached.
ALWAYS install the pans on the work area or an area that is next
to/level with the work area.
DO NOT lift the trowel when the pans are attached.
13.6.1 Lift the trowel just enough to slide the pan under the blades. With
the blades adjacent to the Z-clips, lower the finisher onto the pan.
13.6.2 Rotate the blades into position under the Z-clips. Ensure that the
blades are rotated in the direction of travel when the machine is in
operation. Or, use the engine to rotate the blades into position.
13.6.3 Attach the blade tie-downs to the far side of the Z-clip brackets with
tie-down knobs.
