- 5 -
clamps. Position 2" hose clamps and tighten (as
shown).
5.Cover the rubber elbows on the other ends of the
header pipe with a 2" hose clamps. Position 2" hose
clamps and tighten(as shown).
6.1 lf connect to the soft hose, insert the D32-38mm
hose adapter the rubber elbow. Position 2.5" hose
clamps and tighten(as shown).
6.2 If connect to D50mm PVC pipe, do not install
theD32-38mm hose adapter to the rubber elbow. You
can connect to the PVC pipe directly. Then position
2.5'hose clamps and tighten(as shown)
7. Turn off the pool pump.
8. Go to pool and plug the round return fitting on the
pool wall from the inside so the water won't drain
through(a winter plug works well ).
9.Connect a hose from the filter to the lower elbow
connector.Always fill the system from the bottom.
10.Connect the other hose from pool return fitting to
the other elbow connector.
11. From the inside of the pool wall, remove the plug you placed in the
round return fitting.
YOU ARE NOW READY TO START-UP YOUR SOLAR POOL HEATER
12. Turn on the pump. Check for leaks and tighten the connections that
need attention.
Note:Upon start-up you will see air bubbles come through the return
hose.This is normal and will stop after all the air has been purged from the
solar heating system.
How Well Does Solar Heating Work?
A properly sized and installed system will raise pool temperatures up to
10F during the season. You will only want to circulate water through the
solar collector when the sun is shining. When it's cloudy or rainy, solar
won't work as well(and you probably won't be swimming during those
