Table of Contents Rev. 4/2/2021 PRCT-HD MANUAL
Table of Contents Copyright 2017 Vestil Manufacturing Co. Page 6 of 7
LOADING THE CART
This cart is designed to carry sheet material. Set sheet material on the deck. Carefully lay it against
the supporting frame. Center the material on the deck. If necessary, adjust the location of the material
so that it balances. Evenly distribute the load over the deck. Apply both caster brakes on the swiveling
casters (16-132-053) whenever the cart is parked. Press down on a brake lever to apply the brake. Lift
the lever to release the brake. Push the cart to move it. Do not pull the cart.
RECORD OF SATISFACTORY CONDITION
Before using the cart for the first time, make a record of its appearance and operation. Thoroughly
photograph the unit. Include close-range photographs of each label applied to the unit, the
attachment points of each rail, the casters and bulldog caster receivers. Collect all photographs and
writings into a single file. This file is a record of the unit in satisfactory condition.
INSPECTIONS & MAINTENANCE
Compare the results of each inspection to the RECORD OF SATISFACTORY CONDITION
to determine
whether the unit is in satisfactory condition. DO NOT use the cart unless it is in satisfactory condition. Only
use manufacturer-approved replacement parts to restore the unit to satisfactory condition. DON’T
GUESS! If you have any questions about the condition of your unit, contact the
TECHNICAL SERVICE
department. The phone number is provided on the cover page of this manual. Never make temporary
repairs of damaged or missing parts. Purely cosmetic changes, such as chipped paint, are not changes
from satisfactory condition. However, touchup paint should be applied to all areas where the finish is
damaged as soon as the damage occurs because exposed metal rusts. Left unaddressed, rusting could
compromise the soundness of the metal and create a safety hazard.
At least once per month:
1. Inspect all rail fasteners and the caster fasteners (pins or nut-and-bolt kits). Confirm that all
hardware is in satisfactory condition. Tighten loose connections. Replace loose lock nuts and
fasteners that are broken or severely worn.
2. Inspect all 4 casters and the bulldog caster receivers. Replace a caster if its wheel is significantly
worn, e.g. does not roll smoothly. Lubricate wheel pivot points as necessary to allow for quiet,
uniform rotation. Inspect each caster fork, bearing, axle, wheel hub, mounting plate, and brake
lever (swiveling casters only) for damage.
3. Examine the deck and each rail for significant wear, bends, punctures, cracked welds, and other
forms of damage. The deck must be rigid and square. Rails must not wobble or lean. If a rail is
damaged, contact the factory to order a replacement. If the deck is damaged, it must be
replaced.
LABELING DIAGRAM
Label content and location are subject to change so your product might not be labeled exactly as
shown. Compare this diagram to the RECORD OF SATISFACTORY CONDITION
. Replace all labels that are
damaged, missing, or not easily readable (e.g. faded). Order replacement labels by contacting the
TECHNICAL SERVICE AND REPLACEMENT PARTS DEPARTMENT online at
http://www.vestilmfg.com/parts_info.htm. Alternatively, you may request replacement parts and/or
service by calling (260) 665-7586 and asking the operator to connect you to the Parts Department.
B: Label 658 – Hazards of improper use
A: Label 1153 – Product data label.
C: Label 212 – Apply caster brakes
C
A
B
