3. TO ADJUST RELEASE DEVICE
On the handle of the pallet truck, you will find the control lever (H106) which can be set
in three positions (See Fig. 1):
LOWER=to lower the forks; NEUTRAL=to move the load; ASCENT=to raise the forks.
After assembling the handle, you can adjust the three positions.
3.1 First tighten the setting screw (140H) on the crank link (5010) until the LOWER position
function works.
3.2 If the forks elevate while pumping in the NEUTRAL position, turn the setting screw
(140H) clockwise until pumping the handle does not raise the forks and the NEUTRAL
position functions correctly.
3.3 If the forks descend while pumping in the NEUTRAL position, turn the setting screw
(140H) counter-clockwise until the forks do not lower.
3.4 If the forks do not descend when the control lever (H106) is in the LOWER position, turn
the setting screw (140H) clockwise until raising the control lever(H106) lowers the forks.
Then check the NEUTRAL position as per item 3.2 and 3.3.
3.5 If the forks do not lift while pumping in the ASCENT position, turn the setting screw
(140H) counter-clockwise until the forks elevate while pumping in the ASCENT position.
Then check the NEUTRAL and LOWER position as per item 3.2, 3.3 and 3.4.
4. MAINTENANCE
4.1 OIL
Please check the oil level ever
y six months. The oil cap
acity is about 0.3lt. Restore the fluid
level in the rubber reservoir to 5mm below the top, this must be with the forks in the lowered
position.
Add or change the hydraulic oil according to the table below.
Temperature Oil
-20℃~+40℃
L-HV46 Hydraulic oil
4.2 HOW TO EXPEL AIR FROM THE PUMP UNIT
Air may enter the unit when the seals are replaced. Lift the control lever (H106) to the
LOWER position, then move the handle up and down for several times.
4.3 DAILY CHECK AND MAINTENANCE
Daily check of the pallet truck can limit wear and tear of the unit. Pay special attention to the
wheels (5031, F5008), the axles (F5006, F5009, F5011, F5014), the handle (H801), the
forks (F5002) and lift and lower control. When the truck is not being used, it should be left in
the lowered position.
4.4 LUBRICATION
Use motor oil or grease to lubricate all moveable parts.
5. SAFETY RULES AND OPERATING INSTRUCTIONS
For safe operation of the Hand Pallet Truck, please read all warning signs and
instructions here and on the pallet truck prior to use.
5.1 Safety rules
Page 5 of 14
PM10, Manual.doc
HO150
