TABLE OF CONTENTS Rev. 9/30/2021 LAD-FM-PSO, MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Co. Page 15 of 21
Step 10: a) Attach a pivot mount bracket (44-516-036) to each of the side rail mounting brackets as
shown in the following diagram. b) Attach a rail pivot bracket (44-516-035) to each side rail.
Step 11: Attach the handrail assemblies made in step 9 to the siderails. To make connections b and
c, set rollers on roller receivers and slide the spacers welded onto the upper and lower rail posts onto
the
3
/
8
”-16 x 3
3
/
4
” bolts installed in the brackets in step 10. Tighten
3
/
8
”-16 jam nuts (36206) on the ends of the
bolts. Use
3
/
8
” – 16 x 2
1
/
4
” bolts (11112) and
3
/
8
” -16 lock nuts (37024) to make attachment a.
Welded
spacer
Mezzanine
Pivot mount bracket
Rail pivot bracket
3
/
8
”-16 x 2
1
/
2
” bolt +
3
/
8
-16 lock nut (36206)
3
/
8
”-16 x 3
3
/
4
”
bolt (11118))
3
/
8
”-16 x 3
3
/
4
” bolt
(11118)
3
/
8
”-16 x 1
1
/
4
” bolt (11107)
+
3
/
8
-16 lock nut (37024)
3
/
8
”-16 x 1
1
/
4
” bolt
(11107)+
3
/
8
-16 lock
nut (37024)
Handrail assembly
a
b
c
a
b
c
Welded
spacer
3
/
8
” – 16 x 2
1
/
4
” bolt
3
/
8
” – 16 jam nut
3
/
8
” – 16 jam nut
a
b
Roller
receiver
