Table of Contents 3/30/2020 HBD MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 3 of 21
SIGNAL WORDS
This manual classifies personal injury risks and situations that might cause property damage with signal
words. Signal words indicate the seriousness of injuries that might result if a particular act does, or does
not, occur.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.
SAFETY INSTRUCTIONS
We strive to identify all hazards associated with the use of our products. However, material handling is
dangerous and no manual can address every risk. The most effective way to avoid injury is for the end-user to
exercise sound judgment whenever using this product.
Electrocution might result if any part of the dumper contacts electrified wires. Reduce the likelihood
that platform occupants or bystanders might be electrocuted by applying common sense:
DO NOT contact electrified wires with any part of the dumper;
DO NOT install the HBD in an area where contact with electrified wires is likely;
DO NOT use the dumper close to electrified wires or other sources of electricity;
Before using the dumper, always inspect the usage area for unusual conditions that require special precautions.
Material handling is dangerous. Improper or careless operation might result in serious personal
injuries sustained by the operator(s) and/or bystanders. Work platform users should conform to the following:
• ONLY use the box dumper as a means for mechanically emptying appropriately sized (see “Load the dumper” on
p. 4-5) boxes, crates and other containers. ALWAYS properly load the dumper according to the directions on p. 4-5.
• DO NOT use a damaged dumper. Examples of structural damage include: broken container restraining tube,
broken fork pockets, and holes caused by rust or corrosion. Inspect the dumper before each use according to the
INSPECTION instructions on p. 5. DO NOT use the HBD unless it passes every element of the inspection, or until
authorized maintenance personnel approve the dumper for service.
• Inspect the unit before each use according to the INSPECTION instructions on p. 5.
• DO NOT stand beneath or travel under the dumper chute while it is elevated or allow others to do so.
• DO NOT use this machine UNLESS each label shown in the LABELING DIAGRAM on p. 21 is affixed to it,
undamaged, and readable. Contact TECHNICAL SERVICE to order replacement labels.
• DO NOT exceed the maximum rated load (capacity) of the dumper. The weight of the container to be dumped
plus the weight of its contents must not exceed the maximum rated load of the dumper.
• DO NOT modify the box dumper in any way without first obtaining written approval from Vestil. Unauthorized
modifications might make the dumper unsafe to use, and could result in operator and/or bystander injury.
• Standard units are not designed for high cycle use. High cycle use of a standard unit could lead to premature
failure of the main hinge pins. High cycle us is defined as 12-15 motor starts per hour for 3 or more consecutive
hours.
DO NOT fill the hydraulic system with brake fluid or jack oils. Only fill the hydraulic system with
either anti-wear hydraulic oil, viscosity grade 150 SUS at 100°F (ISO 32cSt at 40°C) or Dexron transmission fluid.
RECORD OF SATISFACTORY CONDITION
Before putting this machine into service, document its appearance and operation. Photograph the unit from
multiple vantage points in the lowered and fully elevated/dumping position. Take close range photographs of all
labeling applied to the machine. Also photograph pivot points and fasteners (pins, bolts, nuts, etc.). Describe the
motion of the chute as it elevates and descends, e.g. smoothly and evenly from side-to side without binding or
lurching. Describe the sound of the machine as it operates. Collate all photographs and writings into a file and mark
the file appropriately to identify it. This file is a record of the unit in satisfactory condition. Compare the results of all
inspections to this record to determine whether the machine is in satisfactory condition. Purely cosmetic changes,
like damaged surface coating (powdercoat or paint), are not changes from satisfactory condition.
