Table of Contents Rev. 9/25/2023 FMDL MANUAL
Table of Contents Copyright 2023 Vestil Manufacturing Co. Page 5 of 20
FMDL-2 EXPLODED VIEW AND BILL OF MATERIALS (40-006-004)
NOTE 1: “Drum gripper assembly” comprised of items 10-27 (shaded).
NOTE 2: In order for the Eagle Beak™ mechanism to work properly,
each drum and its contents must weigh AT LEAST 50 lb.
(~22.7kg).
Item
Part No.
Description
Qty.
Item
Part No.
Description
Qty.
1
40-514-008
Weldment, frame
1
13
40-612-004
Pin, clevis,
7
/
8
” x 1
3
/
4
” long,
with washer
2
2
40-112-001
Pin, main, clevis,
4
14
21-112-003
Pin, clevis,
1
/
2
” x 1
3
/
4
” long
4
3
40-514-022
Drum gripper assembly
2
15
40-016-053
Lower jaw, Eagle Beak™
2
4
40-516-008
Weldment, bracket,
mounting bar
1
16
40-514-011
Weldment, pin bracket
2
5
65125
Cotter pin, zinc plated,
3
/
16
” x 1
1
/
2
”
4
17
40-014-054
Weldment, channel
2
6
99-112-004
Pin, self-locking quick
release
2
18
28-112-031
Pin, clevis,
3
/
4
” x 4
1
/
4
”
4
7
09-145-018
5
/
16
” chain 56” long
1
19
40-612-006
Weldment, pin, cradle
retainer
2
8
40-145-008
Specialty hardware, snap
hook,
5
/
16
”
1
20
40-014-093
Drum cradle
2
9
40-145-008
Strap with ratchet, 6’ long,
2 hooks
1
21
40-146-001
Spring, tension, 6
1
/
2
”
2
10
28-112-031
Pin, clevis,
3
/
4
” x 4
1
/
4
”
2
22
37018
Lock nut,
1
/
4
” - 20
4
11
45286
Clip, hitch pin,
1
/
8
” x 2
5
/
8
”
6
23
40-014-029
Frame, bar, formed
2
12
40-016-052
Upper jaw, Eagle Beak™
2
24
11003
Bolt, hex head,
1
/
4
” - 20 x
3
/
4
”
4
Quick
link
Attach hook of ratchet
strap
