Table of Contents Rev. 7/24/2024 CYL-2, MANUAL
Table of Contents Copyright 2024 Vestil Manufacturing 7 of 9
ii. Forklift: Adjust the positions of the forks on the fork carriage as necessary to match the spacing
of the fork tubes. Drive forward and insert the forks into both fork tubes. Drive as far forward as
possible. For example, drive forward until the forks wedge into the channels.
Step 2: Raise the cart a few inches above the ground. Observe the cart to determine whether the
cart is stable and secure.
Step 3: Transport the cart to the desired location.
i. Overhead hoist: Lift the cart ~5-6 inches above the ground. Stand behind the cart. Grasp the
back of the tool tray or upright/post and carefully direct the cart to the desired location.
Minimize load swing by moving the hoist slowly and carefully.
ii. Forklift: Drive slowly, particularly while turning. Reduce speed during turns. Apply the brakes
gradually to prevent jarring the cart or causing it to slide towards the tips of the forks.
Step 4: Before lowering the cart, make sure that it is not swinging, spinning, etc. Slowly lower the cart
until there is slack in the hoist cable/chain or the forks are loose inside the fork tubes. Disconnect the
cart from the hoist, or dismount the cart from the forklift.
LOADING CYLINDERS ONTO THE CART
Step A. Place the cylinder on the cart. Position the cylinder so that it rests firmly against the
crossbars.
Step B. Release the ratchet to extend the strap, if necessary. To release the ratchet, pull the release
lever toward the handle and pivot the ratchet handle as far from the ratchet base is it will travel
(approximately 180 degrees). By pulling on the strap now, it will unwind from the spindle and
increase the usable length. Ratchet parts are identified in Fig. B on p. 6.
Step C. Wrap the ratchet straps around the cylinder and connect to the J-hook to the J-hook slots
of the divider.
Step D. Pivot the handle back towards the base and let go of the release lever.
Step E. Tighten the strap against the cylinder by moving the handle towards and away from the
base.
Step F. To remove a cylinder from the cart, release strap tension by following the procedure
described in step B.
RECORD OF SATISFACTORY CONDITION (THE “RECORD”)
Before using this cart for the first time, create a record of its appearance and features. Photograph
the unit from multiple angles so that all features are clearly imaged. Take close range photographs of
the ratchets and straps, the divider and its lifting eye, labels, handle grips, wheels, fork pockets, and
welds. Collect all writings and photographs in a file. This file is a record of the unit in satisfactory
condition. Compare the results of all inspections to this Record to determine whether the unit is still in
satisfactory condition. Restore the cart to satisfactory condition BEFORE using it again. Cosmetic
changes, like damaged surface coating (paint or powdercoat) are not necessarily changes from
satisfactory condition. However, touchup paint should be applied as soon as damage occurs to
prevent rusting. Left untreated, rusting could compromise the integrity of the affected metal.
INSPECTING & MAINTAINING THE CYLINDER CART
Inspections and repairs should only be performed by qualified persons. Compare the results of each
inspection to the RECORD OF SATISFACTORY CONDITION (the “RECORD”). Do not use the cart unless all
parts are in satisfactory condition. Replace parts that are not in satisfactory condition before using the
cart again. DON’T GUESS! If you have any questions about the condition of your cart, speak with
TECHNICAL SERVICE personnel. The phone number is provided on the cover page of this manual. Never
make temporary repairs of damaged or missing parts. Only use manufacturer-approved replacement
parts.
Make a dated record of each inspection that includes observations and descriptions of repairs and
replacement parts installed.
Inspect the cylinder cart at least once per mont h.
1. Examine the frame for cracked welds, metal fatigue, rust, and corrosion that affects the structural
integrity of the cart. The structure should be clean, square and rigid, and free of rust and corrosion.
Remove dirt and debris.
