Je bekijkt pagina 13 van 17
- 12 -
26. Steel ball 7
1
78. Dormant bolt M8×14
2
27. O-ring d20×2.65
1
79. Washer
2
28. Y-ring d20×D28×5
1
80. Wheel
2
29. Pump plunger
1
81. Nylon washer
2
30. Spring
1
82. Washer 6
4
31. Spring
1
83. Nut M6
6
32. Pump bass
1
84. Chassis
1
33. Mesh
1
85. Hex soch screw M6×16
1
34. Washer d5×D9
1
86. Fix slider
4
35. Spring
2
87. Movable slider
4
36. O-ring D14×2.4
1
88. Screw bolt M10×70
1
37. Plug
1
89. Bushing
1
38. Reflux rod
1
90. Scissors lever
1
39. O-ring d4×1.8
1
91. Table
1
40. Guide casing
1
92.
Handle knob M12×φ40
1
41. O-ring d10.6×2.65
1
93. Nut M8
1
42. Supporting block
2
94. Control link
1
43. Lever
1
95. Anchor plate for control link
1
44. Split pin 1.6×10
2
96. Steel wire
1
45. Pin
1
97. Tube for steel wire
1
46. Adjust bushing
1
98. Handle
1
47. Nut M8
2
99. Screw bolt M8×20
1
48. Steel ball 5
1
100. Bolt M5×10
4
49. Spring base
1
101. Spring washer 5
4
50. Regulating pressure spring
1
102. Washer 5
4
51. Regulating pressure screw
1
103. Bolt
1
52. O-ring d7.1×1.8
1
104. Tension spring
1
