CZD203 LIFT TABLE SPARE PARTS LIST
No. Description. Qty's No. Description. Qty's
1. Piston rod
1
53. End cover
1
2. Oil cup M6
1
54. O-ring d10×2.65
1
3. Guide ring
1
55. Filler screw
1
4. Y-ring d40×D48×5.5
2
56. Retainer 10
1
5. Guide ring
1
57. Split pin 3×30
1
6. Cylinder
1
58. Partition set
2
7. Split pin 4×30
1
59. Roller
1
8. Spring base
1
60. Pin
1
9. Spring
1
61. Pedal holder
1
10. O-ring D22×2.4
2
62. Pin
1
11. Screw
1
63. Nut M6
2
12. Seal ring 14
4
64. Spring washer 6
2
13. High pressure hose
1
65. Hex soch screw M6×40
2
14. Joint
2
66. Pedal rubber
1
15. Oil retum hose
1
67. Rubber bushing
1
16. Check ring
2
68. Wheel
2
17. Elbow
2
69. Washer
2
18. Seal ring 10
2
70. Nut M10
5
19. Adjust casing seat
1
71. Buffer mat
1
20. Adjust casing
1
72. Screw bolt M10×50
2
21. Spring base
1
73. Washer 10
3
22. Check valve spring
1
74. Bolt
8
23. Conical valve
1
75. Bakelite handle
2
24. Check valve casing
1
76. Guardrail
2
25. O-ring d6.9×1.8
1
77. Screw bolt M6×20
4
CART-400-D-HR
