Table of Contents 2/13/2024 ALL-T-1-GPT-ST-L MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 9 of 15
BILL OF MATERIALS (50-006-030-MANUAL)
Item
Part no.
Description
Qty.
1
50-514-041
WELDMENT, FRAME
1
2
50-538-003
WELDMENT, CARRIAGE
1
3
20-110-009
BEARING, BALL
2
4
38-112-019
PIN, HINGE PIVOT
2
5
33424
MACHINE BUSHING, LOW CARBON, PLAIN FINISH, Ø3/4" X 18 GA
4
6
68015
EXTERNAL RETAINING RING,PHOSPHATE, 3/4"
4
•7
50-612-008
ASSEMBLY, AXLE, REAR WHEEL
1
••8
50-525-002
WELDMENT, STEER HANDLE
1
•••9
50-542-005
SUB-ASSEMBLY, SPROCKET, DRIVE, LEFT
1
••••10
50-542-006
SUB-ASSEMBLY, SPROCKET, DRIVE, RIGHT
1
11
50-145-002
COUPLER,DRIVE SHAFT COUPLING
1
12
50-026-002
SHAFT, DRIVE SHAFT
1
13
50-540-006
WELDMENT, SHIFTER PLATE
1
14
50-024-011
COVER, REAR BELT COVER
1
15
50-024-012
COVER, LOWER BELT COVER, FORMED
1
16
50-024-014
COVER, SKID PLATE
1
17
50-024-006
COVER, REAR LEG
2
18
50-024-016
COVER, LEG, FRONT
2
19
50-028-001
FORK
2
20
99-145-105
SPECIALTY HARDWARE, U-NUT, 1/4"-20
11
21
29185
SCREW, MACHINE, TRUSS HEAD
13
22
25326
SOCKET SET SCREW, BLACK OXIDE, 1/4-20 X 1/4"
2
23
11114
HHCS #2 Z PLATED, GRADE A, Ø3/8 - 16 x 2 3/4 LG
4
24
36106
HEX NUT, GRADE A, ZINC PLATED, 3/8-16
4
25
50-145-009
SPEC. HARDWARE, TRANSAXLE LINK, THREADED ROD
1
26
50-145-011
HARDWARE, INTERNALLY THREADED BALL JOINT LINKAGE
2
27
01-118-001
BOLT, CYLINDER RETAINING
1
28
23203
SHCS, UTILITY GRADE, 1/4 - 20 x 3/4 LG.
1
29
36102
HEX NUT, GRADE A, ZINC PLATED, 1/4-20
3
30
50-130-006
PIN, KEY, AXLE EXTENSION
1
31
32416
THREAD CUTTING SCREW, SLOTTED, TYPE F, ZINC PLATED, 5/16-18 X 3/4
4
32
11059
Ø5/16-18 UNC x 1-1/2 LG, Z-PLATED, #2, GRADE A
1
33
99-145-104
SPECIALTY HARDWARE, U-NUT
2
34
99-021-912-001
CYLINDER, HYDRAULIC, Ø1 1/2" x 48", TELESCOPIC STYLE
1
35
38-113-005
SPACER
4
36
38-027-001
CARRIAGE, BEARING, ROLLER
4
37
38-024-015
ROLLER, END CAP
4
38
94257
FHSCS 5/16-18 x 1 1/4
4
39
50-112-022
TRANSAXLE, 3/4" SHAFT
1
40
50-016-071
BRACKET, BRAKE CABLE, FORMED
1
41
50-040-013
LEVER, BRAKE
1
42
50-145-013
HARDWARE, BRAKE CABLE
1
43
50-016-072
BRACKET, NEUTRAL, BRACKET FORMED
1
44
50-525-010
WELDMENT, HANDLE, DRIVE TO NEUTRAL
1
45
43520
ADJUSTABLE YOKE END, 2" X 7/16" X 5/8" X 1/4"-28
1
46
65012
COTTER PIN Z PLATED, Ø1/16 x 1/2 LG
1
47
66026
PIN, CLEVIS ø1/4" x 1" LG.
1
• Item 4 shown in Rear Wheel Axle Assembly Exploded View on p. 10.
•• Item 6 shown in Steering Handle Subassembly Exploded View on p. 11.
••• Item 7 shown in Sprocket Drive Subassembly, Left Side, Exploded Views on p. 13.
•••• Item 8 shown in Sprocket Drive Subassembly, Right Side, Exploded Views on p. 13.
* Components of Power Unit Subassembly 50-160-002 on p. 12.
