Table of Contents 2/13/2024 ALL-T-1-GPT-ST-L MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 11 of 15
Steering Handle Subassembly Exploded View and Bill of Materials
50-525-002
Item
Part no.
Description
Qty.
Item
Part no.
Description
Qty
.
1
50-113-002
Spacer, air spring
2
14
50-145-003
Specialty hardware, shifter
cable
1
2
50-113-03
Spacer, handle
2
15
11113
Hex bolt, gr. A, plain,
3
/
8
”-
16x2
1
/
2
”
2
3
50-525-003
Weldment, steering
handle
1
16
43520
Adjustable yoke end,
2”x
7
/
16
”x
5
/
8
”x
1
/
4
”-28
1
4
50-540-004
Weldment, shifter lever
1
17
50-120-001
Nut, brake
1
5
50-525-004
Weldment, safety bale
1
18
66026
Pin, clevis,
1
/
4
”x1”
1
6
99-145-015
Specialty hardware,
shock, tension
1
19
65012
Cotter pin, z-plated,
1
/
16
”x
1
/
2
”
2
7
11109
Hex bolt, gr. A, zinc finish,
3
/
8
”-16x 1
1
/
2
”
1
20
50-146-002
Spring, kill switch
1
8
37024
Nylon insert lock nut, gr. 2,
z-finish,
3
/
8
”-16
3
21
33004
Flat washer, USS, z-plated,
1
/
4
”
1
9
11117
Bolt, HHCS, #2, z-plated,
3
/
8
”-16x3
1
/
2
”
4
22
11010
Hex bolt, gr. A, z-plated,
1
/
4
”-20x1
3
/
4
”
1
10
36106
Hex nut, gr. A, z-plated,
3
/
8
”-16
4
23
50-022-001
Switch, PB SPST, normally
closed
1
11
11013
Bolt, HHCS, #2, z-plated,
1
/
4
”-20x2
1
/
2
”
1
24
50-022-002
Switch, PB SPST, normally
open
1
12
37018
Nylon lock nut, gr. 2, z-
finish,
1
/
4
”-20
3
25
50-034-001
Boot, switch
2
13
11009
Hex bolt, gr. A, z-plated,
1
/
4
”-16x1
1
/
2
”
1
26
50-514-040
Weldment, frame, handle
mount
1
Return to p. 9
