EN - 15
Button monitoring is included to prevent the
appliance from unwanted button operation. In
cases where one or more buttons are pressed for
longer than 12 seconds, the buzzer will sound for
ten minutes to indicate an incorrect operation.
For example, an object may be placed on a
button, or there could be a sensor failure and so
on.
The safety switch-off will cause the hob to go
into S-mode and all heater displays will flash
“F”. If there is no incorrect operation present,
both the visual and audible signals will
disappear.
If residual heat is present, “H” will be displayed
on all other heater displays.
Over Temperature Switch-Off
Due to the controls being very close to the
heater in the middle of the front of the hob, it
can occur that an incorrectly placed pot is not
sensed by the sensor safety cut-off therefore
heating up the hob to a very high temperature.
This makes the glass and the buttons dangerous
to touch.
To prevent the hob control unit from damage,
the controls constantly monitor the temperature
and switch off if overheating occurs.
This will be indicated by the letter “t” in the
heater display until the temperature decreases.
Once the temperature has dropped, the “t” in
the heater display will disappear and the hob
control unit will revert back into
.
S-Mode. This means that the user can
reactivate the appliance by pressing
Operating Time Limitations
The hob control unit has a limitation on the
operating time. If the heat setting for a heater
has not been changed for a certain time, the
heater will switch off automatically. A “
0” will be
displayed for 10 seconds, however there may be
some residual heat present. The limit of the
operating time depends on the selected heat
setting.
After a heater automatically switches off, as
described above, the heater can be used and
the maximum operating time for this heat
setting is applied.
Residual Heat Functions
After all cooking processes, some heat will be
stored in the vitroceramic glass called residual
heat. The appliance can calculate roughly how
hot this glass is. If the calculated temperature is
higher than
+ 60 ° C, then this will be indicated in the
corresponding heater display for as long as the
calculated temperature remains above
+ 60 ° C, even after the appliance has been
switched off.
The residual heat indicator has the lowest
priority and is overwritten by every other display
value, including during safety switch-off and the
displaying of an error code. When voltage is
supplied to the hob after a power interruption,
the residual heat display indicator will flash. If a
heater had a residual heat of greater than + 60
°C before the power interruption occurred, the
display will flash while the residual heat remains
or until the heater is selected for another
cooking operation.
Hints and Tips
Important: When ceramic heaters are
operated in higher heat settings, the
heated areas may be seen switching
on and off. This is due to a safety device, which
prevents the glass from overheating. This is
normal at high temperatures, causing no
damage to the hob and little delay in cooking
times.
WARNING:
• Never operate the hob without
pans on the cooking zone.
• Use only flat saucepans with a sufficiently
thick base.
• Make sure the bottom of the pan is dry
before placing it on the hob.
• While the cooking zone is in operation, it is
important to ensure that the pan is centred
correctly above the zone.
