4.5 Installing the Edge Guard

1. Press edge guard to the top-cover cut outs by pressing along the edge of the cut out opening as shown in the

following figure.

2. Trim excess edge guard with a pair of scissors after the edge guard after completely applied around the opening.

3. Repeat steps 1 and 2 for remaining cut outs.

Figure 4.5 Applying the edge guard

Item Description

1 edge guard

2 Break-away tabs to accommodate the pass-through of large-diameter rack-PDU plugs

4 Installation and Assembly Procedures

14

Vertiv™ VR Installer/User Guide
