30
EN
14. Remove the centre hinge screw hole plug on
the left side of the cabinet, then install in the
screw holes on the right side of the cabinet.
7. Remove the bottom ring and nut securing the pin shaft to the
right hole on the lower hinge, then remove the shaft.
8. Insert the pin shaft into the left hole on the lower hinge,
then secure the shaft with the washer and nut.
9. Install the lower hinge on the left side of the cabinet.
10. Install the adjustment leg removed in step 6 on the right
side of the cabinet.
11. Remove the screw that secures the door stop from the
bottom right of the freezer compartment door, then
remove the door stop and install to the bottom left side.
12. Install the freezer compartment door.
13. Move the door bushing from the top right side of the freezer
door to the top left side of the door. Then move the left hole
cover to the right side.
Pin shaft
Pin shaft
Freezer door
Door stop
Hole cover
Door bushing
Screw hole plug
