29
EN
1. Make sure that your fridge freezer combination is unplugged.
2. Pry the hinge cover up and off, remove the three screws that
secure the upper hinge to the door, then remove the hinge.
3. Remove the refrigerator compartment door from the
cabinet.
4. Remove the two screws that secure the centre hinge.
5. Remove the freezer compartment door.
6. Remove the adjustment leg on the left side of
the cabinet and set it aside for later installation.
Remove the screws that secure the lower hinge to
the right side of the cabinet, then remove the hinge.
7. Mounting accessories
- Adjustable shelves
The walls of the appliance are equipped with a series of guide proles so
that the shelves can be inserted if desired.
- Installing the door compartments
To store food of different sizes, the door compartments can be set to different
heights. Proceed as follows: gradually pull the compartment in the direction
of the arrows until it comes loose and put it in the desired position.
8. Storing food
See Section 4 “Use”.
Necessary tools:
• To remove the door, the appliance must be tilted backwards. We recommend doing this with two people. Rest
the appliance on a rm surface so that it does not slip away as you reverse the door.
• Keep all removed parts to remount the door later.
• During this process, the appliance must be placed on its back. After this, wait four hours before connecting the
appliance so that the oil can ow back to the compressor.
• Crosshead screwdriver • Flat head screwdriver • Spanner
Hinge cover
Screws
Upper hinge
Lower hinge
Screws
Refrigerator compartment door
Center hinge
Screws
3.2 REVERSING THE DIRECTION IN WHICH THE DOOR OPENS
