ENGLISH
20
Error messages
The light strip flashes purple on the short
sides at the same time:
It is not possible to connect to the WiFi net-
work.
The left short side lights up continuously in
red-violet, the right short side flashes, also in
red-violet:
No connection to the VENTA cloud can be
established.
Technical specications AS 100 AS 150
Frequency range 2.4 GHz 2.4 GHz
Max. transmitter power 20 dBm 20 dBm
WiFi Standard IEEE 802.11 b/g/n IEEE 802.11 b/g/n
Dimensions (LxWxH) 207 x 84 x 28 mm
8.15 x 3.3 x 1.1 in
207 x 84 x 28 mm
8.15 x 3.3 x 1.1 in
Weight without power supply unit + cable
Weight with power supply unit + cable
Weight with power supply unit + cable (global)
248 g / 8.75 oz
334 g / 11.75 oz
381 g / 13.65 oz
283 g / 10 oz
369 g / 13 oz
416 g / 14.9 oz
Power consumption 3.5 W 3.5 W
USB pluggable power adapter Input: 100-240 V ~, 50/60 Hz, max. 0.3 A
Output: 5 V = 1.0 A (5.0 W),
Model ADS-6RC-06 05050E
Protection class II
Subject to changes and errors.
