1 Display

[MENU] | Activates the main menu for selecting the operating mode.

[UP] | Increases the displayed value by one.

[DOWN] | Decreases the displayed value by one.

[ENTER] | Selects an option of the respective operating mode, conrms the set value

2 Mounting bracket with locking screws

3 [DMX IN] | DMX input, designed as XLR panel plug, 3-pin

4 [DMX OUT] | DMX output, designed as XLR panel socket, 3-pin

5 [F3AL250V] | Fuse holder

6 Safety cable eyelet

7 [POWER IN] | Lockable input socket (Power Twist) for the power supply of the device

8 [POWER OUT] | Lockable output socket (Power Twist) for powering further devices

Connections and controls

Retro Blinder TRI 380
