7 Operating
7.1 Starting the device
CAUTION!
Risk of injury due to unexpected movements of the device!
The device head may perform fast movements and generate very bright
light. This is the case immediately after the device is switched on, in
automatic or remote operation, and when a connected DMX controller
is switched o. Persons who are in the immediate vicinity of the device
may be injured or frightened by this.
Make sure that there are no obstacles within the movement range of
the mirror, and that no persons are in the immediate vicinity of the head
before switching it on and during its operation.
Switch o the device before any work is performed in the movement
range or immediate vicinity of the device, or if unauthorised persons are
in that area.
Connect the device to the mains to start operation. After a few seconds, the fans start
to work, and the head moves to the home positions for rotation (pan) and inclination
(tilt). The device is now operational.
7.2 Main menu
1. Press [SET] to activate the main menu.
2. Use [UP] and [DOWN] to change the respectively displayed value. When the
display shows the desired value, press [SET].
3. To exit the menu item without making changes, press [ESC].
4. If you do not press a button for 30 seconds the display turns o. Briey
pressing [ESC], [SET], [UP] or [DOWN] will turn it back on.
All previous settings are retained even when you switch the device o and discon‐
nect it from the mains.
Use the ‘DMX Address’ menu to set the DMX address.
1. Press [SET] to activate the main menu.
2. Use [UP] or [DOWN] until the display shows ‘DMX Address’ and conrm with
[SET].
3. Use [UP] or [DOWN] to select a value between ‘001’ and ‘512’ to set the desired
DMX address and conrm with [SET].
Make sure that this number matches the conguration of your DMX controller. The
following table shows the respective highest possible DMX address for the various
DMX modes.
DMX address
Operating
Hero Mirror
13
Moving Head
