UsEr manUaL
www.Vari-LitE.com
VL800 EVEntprofiLE
26
MENU OPERATION
WHAT IS THE MENU SYSTEM?
The menu system is a programmable set of commands used to configure, address, operate, and test the lumi-
naire. The menu system is controlled at the Menu Display available at the enclosure input panel.
CONTROLS OPERATION
The menu system is controlled by [MENU], [ENTER], and four
▲▼ arrow buttons.
The arrows have opposite functions if the luminaire is hung
upside down in a hanging orientation due to the automatic ori-
entation feature. In other words, the arrow pointing downward
always functions as down/decrease and the arrow pointing
upward always functions as up/increase regardless of the lumi-
naire orientation.
DeFaUlT sTaTe
The menu display’s default state during normal operation is to
display the DMX address. After 40 seconds of inactivity at the
display, it will change to the default state.
After longer periods of inactivity, the menu display will switch
to its o state. The default state for this feature is 30 seconds,
however, dierent time lengths can also be programmed.
To program a dierent time length for menu o feature:
Step 1. Press [ESC] access the main menu.
Step 2. Once enabled, the menu will function as normal with only the following sub-menu sections active:
• Address
• Configure
• DMX
• Fixture
• Manual Control
• Test
Step 3. Press ▲▼ choose the “Configure”, and press [ENTER].
Step 4. Press ▲▼ choose the “Display”, and press [ENTER].
Step 5. Press ▲▼ choose the “On Time”, and press [ENTER].
Step 6. Press ▲▼ choose “30 Sec”, “5 Min”, “10 Min”, “On” when you need.
MENU FUNCTIONS
For easy reference, each possible menu item is listed alphabetically in the first column by its display abbre-
viation. The second column follows with a definition of the abbreviation and then a third column provides an
explanation of its purpose and function.
To select any functions, press the MENU button until the required one is shown on the display. Select the func-
tion by the ENTER button and the display will blink. Use the DOWN and UP button to change the mode. Once
the required mode has been selected, press the ENTER button to setup or it will automatically return to the
main functions without any change after idling one minute. Back to the functions without any change press the
MENU button.
Enter Button. To confirm the
selected functions.
LCD Display. Shows menu
and selected functions
Menu Button. To select the
programming functions.
▲▼ Buttons. To go forward/
backward in the selected
functions
