VL800 EVENTPAR RGBA
22
Dim Snap
Dim Snap On allows for fastest output changes between levels but reduces smoothness dimming the
LED engine. Dim Snap O ensures all fades between output levels remains smooth and flicker free but
limits fast, instant snaps between levels. Can also be set via the control channel.
White Balance
White Balance allows for adjustment of the maximum output for RED, GREEN, BLUE, and AMBER in
order to balance a group of fixtures to one another. The adjust for each individual level is 125 to 255.
Meaning if RED is set to 125, a DMX value of 255 would set the RED to a lower then normal level. The
defaults for all are 255.
Output Mode
Standard mode provides full LED output. Studio mode reduces fan speed to reduce the fan noise of the
fixture. Whisper mode decrease the fan noise further. In both Studio mode and Whisper mode, the LED
output will decrease accordingly. Can also be set via the control channel.
Fan Mode
Fan On runs fans at continuous max speed based on Output Mode. Fan Auto will reduce/increase speed
on demand based on LED operating temperature. The fan will not exceed the maximum permissible
level based on Output Mode. Can also be set via the control channel. See Appendix B.
Refresh Rate
Choose the refresh rate of the LED engine (see Display Menu Tree for list).
DISPLAY
Orientation
Sets the orientation of the display. Up should be chosen if the fixture is sitting on its base. Down should
be chosen if the fixture is hanging.
On Time
Sets how long the display remains illuminated after the last button touch. Choose from 30 seconds, 5
minutes, 10 minutes, or always on.
RESET DEFAULTS
Resets all the factory defaults of the fixture. This includes setting the DMX Address to 001.
DMX
ADDRESS
Sets the starting DMX address of the fixture. Can also be set via RDM.
DATA
Allows the current DMX value present on each of the luminaire’s DMX channels to be viewed.
