USER MANUAL
WWW.VARI-LITE.COM
VL5LED WASH
38
UPDATING SOFTWARE
TRANSFERRING SOFTWARE BETWEEN LUMINAIRES
It is possible to transfer specifi c software versions between luminaires. As in the
case of installing new software versions, multiple luminaires can be programmed
at the same time if they are data linked together (refer to Connecting power on
page 4), however a maximum of 16 luminaires can be updated at once.
HARDWARE REQUIREMENTS
A DMX termination connector is used in this process. Refer to page 16 for more
information regarding the construction of this connector.
To transfer software versions between luminaires:
Step 1. At last luminaire, install DMX termination connector into DATA THRU XLR connector.
Step 2. At master luminaire (fi rst in chain) Menu Display, press [ESC].
Step 3. Press ▲▼◄►arrows until Fixture appears.
Step 4. Press ▲▼◄►arrows until Crossload appears. Press [OK].
Step 5. Unplug DMX From Console? will be displayed. Press [OK] to accept.
Step 6. Once download is complete, luminaire automatically recalibrates. Once recalibration is complete,
recalibrate luminaire one additional time.
To Verify software version at luminaire:
Step 1. At Menu Display, press [ESC].
Step 2. Press ▲▼◄► arrows until Fixture appears. Press [OK].
Step 3. Press ▲▼◄►arrows until Version appears. Press [OK].
• Part 1 of the version displays as VXXX.
• Press to display part 2 of version. This displays as a date (MM/DD/YY). For example, 12/25/ 19
(December 25, 2019). Press to display part 3 of version. This will be displayed as a time (HH:MM).
For example, 16.36 (4:36 pm).
DMX 512
(from console
or control device)
DMX 512
(out from first to
second luminaire)
DMX 512
(out to the next
luminaire or DMX512
controlled device)
4 OPERATION
