Installation & User’s Manual SL NITRO 510C LED STROBE Luminaire
44 DMX CONTROL
Sh wline
12. Mapping 16-Bit Mode
Table 20 provides DMX channel mapping of the DMX512 control values when the SL NITRO 510C LED STROBE
Luminaire is in Mapping 16-Bit DMX512 mode (as set by the luminaire’s menu system).
Note: When using pixel mapping software with the SL NITRO 510C LED STROBE Luminaire, it is suggested to
only map the RGB channels and utilize the white channels independently. Refer to "RGB & W Operation" on page 24
for more information.
Table 20: DMX Channel Mapping (Mapping 16-Bit Mode)
DMX
Channel
Parameter Range DMX Range%
Default - recom-
mended console
default values
Description
1 Red 1 - High
0 - 65535 0 - 100% 0 16-bit control of Red 1 LEDs from 0 to full
2 Red 1 - Low
3 Green 1 - High
0 - 65535 0 - 100% 0 16-bit control of Green 1 LEDs from 0 to full
4 Green 1 - Low
5 Blue 1 - High
0 - 65535 0 - 100% 0 16-bit control of Blue 1 LEDs from 0 to full
6 Blue 1 - Low
7 White 1 - High
0 - 65535 0 - 100% 0 16-bit control of White 1 LEDs from 0 to full
8 White 1 - Low
9 Red 2 - High
0 - 65535 0 - 100% 0 16-bit control of Red 2 LEDs from 0 to full
10 Red 2 - Low
11 Green 2 - High
0 - 65535 0 - 100% 0 16-bit control of Green 2 LEDs from 0 to full
12 Green 2 - Low
13 Blue 2 - High
0 - 65535 0 - 100% 0 16-bit control of Blue 2 LEDs from 0 to full
14 Blue 2 - Low
15 White 2 - High
0 - 65535 0 - 100% 0 16-bit control of White 2 LEDs from 0 to full
16 White 2 - Low
17 Red 3 - High
0 - 65535 0 - 100% 0 16-bit control of Red 3 LEDs from 0 to full
18 Red 3 - Low
19 Green 3 - High
0 - 65535 0 - 100% 0 16-bit control of Green 3 LEDs from 0 to full
20 Green 3 - Low
21 Blue 3 - High
0 - 65535 0 - 100% 0 16-bit control of Blue 3 LEDs from 0 to full
22 Blue 3 - Low
23 White 3 - High
0 - 65535 0 - 100% 0 16-bit control of White 3 LEDs from 0 to full
24 White 3 - Low
25 Red 4 - High
0 - 65535 0 - 100% 0 16-bit control of Red 4 LEDs from 0 to full
26 Red 4 - Low
27 Green 4 - High
0 - 65535 0 - 100% 0 16-bit control of Green 4 LEDs from 0 to full
28 Green 4 - Low
29 Blue 4 - High
0 - 65535 0 - 100% 0 16-bit control of Blue 4 LEDs from 0 to full
30 Blue 4 - Low
31 White 4 - High
0 - 65535 0 - 100% 0 16-bit control of White 4 LEDs from 0 to full
32 White 4 - Low
33 Red 5 - High
0 - 65535 0 - 100% 0 16-bit control of Red 5 LEDs from 0 to full
34 Red 5 - Low
35 Green 5 - High
0 - 65535 0 - 100% 0 16-bit control of Green 5 LEDs from 0 to full
36 Green 5 - Low
37 Blue 5 - High
0 - 65535 0 - 100% 0 16-bit control of Blue 5 LEDs from 0 to full
38 Blue 5 - Low
39 White 5 - High
0 - 65535 0 - 100% 0 16-bit control of White 5 LEDs from 0 to full
40 White 5 - Low
