Je bekijkt pagina 22 van 56
Installation & User’s Manual SL NITRO 510C LED STROBE Luminaire
20 OPERATION AND PROGRAMMING
Sh wline
Use the Up and Down buttons to select parameters and the Left and Right buttons to assign the fixture's DMX
settings. When finished, press the Check button to exit the menu level. The adjustable parameters are described in
Table 8.
Settings/Display
Options of the fixture's LCD display can be adjusted in the Display menu.
Use the Up and Down buttons to select parameters and the Left and Right buttons to assign the fixture's DMX
settings. When finished, press the Check button to exit the menu level. The adjustable parameters are described in
Table 9.
Lock Fixture
You can lock all fixture functions, requiring a PIN code to access the menu functions. When you select this menu
item, you are asked to confirm that you wish to lock the fixture. Once locked, all menu items can only be accessed by
entering one of the three PIN codes assigned in the Settings/Security menu. (see "Settings/Security" on page 18 for
more information). The PIN code used to unlock the fixture will only unlock the functionality assigned to that
particular PIN code.
Note: When the fixture is powered off, the Lock Fixture function will be disabled. To assign fixture power-up
security refer to (see "Settings/Security" on page 18 for more information).
Password (PassPIN)
The Password menu item will display an Enter PassPIN dialog box. Use the Up Down Left Right buttons to enter a
PIN code matching the codes assigned in the Settings/Security menu to toggle the current security level.
Status
The Status screen displays the current value of the master intensity and LED zone of the fixture. Use the Up Down
Left Right arrows to scroll through the different zones and view their levels.
• The last Status item displayed shows the RDM UID and current Firmware Version.
• Press the Check Mark button to exit the Status screen.
Table 8: DMX Setting Parameters
Parameter Description
DMX Enable
• Enable - Fixture will respond to DMX commands/signals.
• Disable - Fixture will ignore DMX commands/signals.
Address Assigns the fixture’s DMX start address.
Map
Selects the DMX map for the fixture to use (see DMX CONTROL section for more
information).
When no DMX
Selects the action of the fixture when the unit is powered ON and not receiving DMX.
• Off - Turn off all LED output.
• Last Action - restore the last menu action.
• Power-up - follow the power-up value in the settings menu.
• Hold - continue with the last DMX values received.
LED Group
Selects the number of LED groups to control via DMX (see DMX CONTROL section for
more information)
Table 9: LCD Display Parameters
Parameter Description
Flip Display
• Yes - The display will be inverted.
• No - The display will not be inverted.
• Auto - The display will automatically invert depending upon fixture orientation.
Off Time
Assign a time for the display to automatically turn off after the last button press. A value of
ON will leave the display on indifferently.
Language Select English is the only language currently supported.
