Je bekijkt pagina 22 van 28
F60580A1 VERSA-CNRLBOX-ASSY
Bill of Materials
THE HOSE HAS BEEN MANUALLY ENTERED INTO THIS BOM
BECAUSE THE HOSES ARE EXCLUDED FROM THE BOM IN
THE MODEL TO MAKE THE BILL WORK EASIER TO DO.
ITEM NO.
PART
NUMBER
DESCRIPTION
QTY.
1
Z00111A5
CABLE-BAT BLK 6LG
1
2
Z00113A3
CABLE-BAT RED 15.5LG
1
3
Z00114A2
CABLE-BAT BLK 15.5LG
3
4
Z00547A3
CABLE-BAT 12V-27" RED 7/16X1/4
1
5
Z00548A2
CABLE-BAT 12V-6" RED 7/16X1/4
1
6
F68840A8
UG-CNRLBOX- BASE WLDMT
1
7
Z20814A9
GROMMET-.75IDX1.13HOLEX.09TH
2
8
Z00171A6
BATTERY-12V 100AH SEALED LEAD
2
9
Z00008A1
CIRCUIT BRKR SLA-150
1
10
Z20818A5
SWITCH-BATTERY DISCONN/PD
1
11
Z84909A1
GAUGE-PRESSURE 0-3K PSIG CF1P-
210E**3000PSI 2.5 GLY FLG/PNL MNT
1
12
Z20836A7
GAUGE-BATTERY DISCHARGE
1
13
Z84905A5
GAS SPRING MOUNT STR
1
14
Z84866A4
BALL-10MM - MOUNT PLATE TALL
1
15
Z20362A2
CHRGR-BATTERY 12/24 120VAC
1
16
Z10595A9
RIVET-POP 1/8x1/8 ST
3
17
Z10391A5
NUT-HEX KEPS #10-24
5
18
Z10176A6
S-RHM #10-24X1/2 5
19
Z10035A7
NUT-HEX KEPS 1/4-20
3
20
Z10335A4
S-CRG 1/4-20x3/4 ZP
2
21
Z84869A1
LATCH-DRAW RUBBER
1
22
Z20849A3
FTG 90 2502-4-4
1
23
Z11548A1
S-FHM #4-40X3/8 ZP
3
24
Z10003A5
NUT-HEX KEPS #4-40
3
25
F50804
FELT PAD UG3 BTTM BAT 2.50X50"
1
26
Z10463A8
S-PTHM #8-32x3/8
11
27
Z10382A6
NUT-HEX KEPS #8-32 ZP
11
28
F60575A6
PP-2FUNC 12V
1
29
F60473A1
PENDANT ASSY/FORK ATTACH (KANBAN)
1
30
Z84906A4
GAS SPRING 60 LB 4" STROKE
1
31
Z84897A3
FTG STR 2700-4-4-LN
2
32
Z20704A0
FTG 90 6500-4-4 SWL
2
33
F50432
UG-CNRLBOX-ACCESS PANEL (KANBAN)
2
34
F61932A0
UG-CTL-LID WLDMT
1
35
Z20364A4
BATTERY TERMINAL COVER - RED (LARGE)
2
36
F61016A7
HOSE-17.50/613/648
1
37
F61297A2
HOSE-16.50/613
2
38
Z20736A8
HOSE-20.00/613
2
39
Z00614A0
PLUG HOLDER 120V
1
22
