F60559A0 UG-JAW ASSY 18-28 MAXI
Bill of Materials
THE HOSE HAS BEEN MANUALLY ENTERED INTO THIS BOM
BECAUSE THE HOSES ARE EXCLUDED FROM THE BOM IN
THE MODEL TO MAKE THE BILL WORK EASIER TO DO.
ITEM
NO.
PART
NUMBER
DESCRIPTION
QTY.
1
F50401
CYL PIN 1.25 UG3 FRT SECT (KANBAN)
2
2
F50435
RD-2.00/UG3 JAW ASSY CYL SPCR
4
3
F50438
SHT-.19/UG3 JAW ASSY SPRG CLIP (STK)
4
4
F60560A1
ARM WLDMT MAXI II
1
5
F68824A2
UG-JAW-SADDLE WLDMT-15-30 (9") (STK)
1
6
F68825A3
UG-JAW-WLDMT-18-28 (9") (STK)
2
7
F68832A0
UG-JAW-PIN WLDMT-20-35
2
8
Z10026A8
NUT-HEX JAM 3/8-16ZP
4
9
Z10534A4
RING-RTNG 1-1/4
6
10
Z10592A2
BUSH-MACH 1-1/4X10GA ZP
6
11
Z11484A3
CONNECTOR 3/8-16 SPRING
4
12
Z11485A2
SPRING-EXTENSION 1.00X.14X8.00
4
13
Z20616A6
FTG 90 6801-4-4 NWO
2
14
Z20813A0
GROMMET-.75IDX1.06HOLEX.25TH
2
15
Z20830A3
BRG-BRZ-FLG 1.25X1.50X1.50
4
16
Z20845A8
CYL ASSY-UG3 CLAMP 1.13ROD
(319392)
1
17
Z84897A3
FTG STR 2700-4-4-LN
2
18
Z11572A7
S-BHCS 1/4-20X3/4 ZINC
10
19
F61348A1
HOSE-20.00/613/649
2
19
VERSA II-2K# SP, CLAMP & TILT
