1 9471003
CAUTION: To reduce the risk of electric shock,
Do not remove cover. No user serviceable parts inside.
Refer servicing to qualified service personnel.
Do not expose this apparatus to rain or moisture. Apparatus shall
not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
ISSUE 1
ezIP 24 PORT ONE-WAY GATEWAY
EZ-GW24
INTRODUCTION
The EZ-GW24 One-Way Gateway is designed for
applications using analog 25 Volt, 45 Ohm or Self-
Amplified speakers. The EZ-GW24 is ideal for
modernizing existing analog paging systems. The
EZ-GW24 One-Way Gateway supports 24 paging
zones. The EZ-GW24 uses Valcom’s ezIP
protocol but can be upgraded to VIP protocol for
compatibility with standard Valcom IP products.
SPECIFICATIONS
Features
24 Zone/Speaker Connections
Zone output can be programmed for 25 Volt
speakers, 45 Ohm speakers or Line Level
RJ-45 for network connection
Front panel activity LED
Compatible with Valcom ezIP Protocol,
upgradable to Valcom VIP Protocol
Dimensions/Weight
1 Standard 19” Rack Unit
1.75” H x 16.50" W x 15.0" D
(4.5cm H x 41.9cm W x 38.1cm D)
Weight: 6.20 lbs. (2.8 kg)
Nominal Specifications
Zone Outputs 45 Ohm Impedance
Line Level Output -10 dBm
Nominal Power Requirements
100-240Vac, 2.5A, 50/60Hz
These products use an internal UL Listed power
source rated 24VDC.
Environment
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
Precautionary Designations
WARNING-To Reduce The Risk Of Fire Or
Electric Shock. Do Not Expose This
Apparatus To Rain Or Moisture.
• AVERTISSEMENT - Afin de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système à la
pluie ou à l'humidité.
Apparatus shall not be exposed to dripping
or splashing and no objects filled with
liquids, such as vases, shall be placed on
the apparatus.
• L’appareil ne doit pas être exposé à des
égouttements et éclaboussures et aucun
Objet Rempli de liquide, comme vase, ne
doit être placé sur l’appareil.
