2.6 Grounging Design
There are 1 external grounding terminals at the front and back of energy storage system, as shown
in Figure2-10.
Figure2-11 Cabinet grounding terminals diagram
2.7 Wiring Holes Design
The connection wires between the energy storage system and the inverter have been
pre-connected. You just need to open the wire trough cover and take them out.
Figure2-12 Inside the wire trough
M8 screw
