- 20 -
3.8 WIFI Connecon
For the configura�on of Wi-Fi Plug, please refer to illustra�ons of the Wi-Fi Plug. The Wi-FI Plug
is not a standard configura�on, it's op�onal.
The conductor should be made of the same metal as the phase conductors.
3.7 Earth Connecon(mandatory)
Ground cable shall be connected to ground plate on grid side, this prevents electric shock if the
original protec�ve conductor fails.
Note:
When the inverter is in the off-grid state, the N line needs to be connected to the
earth.
Note:
In final installa�on,breaker cer�fied according to IEC 60947-1 and IEC 60947-2
shall be installed with the equipment.
Earth Connec�on (Copper wires) (bypass)
Model
29.9/30/35/40/50kW
Wire Size
0AWG
Cable(mm )
2
50
Torque value(max)
28.2Nm
Earth Connec�on (Copper wires)
Model
29.9/30/35kW
40kW
Wire Size
6AWG
Cable(mm )
2
10
Torque value(max)
12.4Nm
4AWG 16 12.4Nm
50kW 4AWG 16 16.9Nm
