2-5
Before Using the Fax Machine > Part Names and Functions
Touch Panel
Home Screen
This screen is displayed by selecting the [Home] key on the operation panel. Selecting an icon will display the
corresponding screen.
You can change the icons to display on the Home screen as well as its background.
Machine’s Operation guide
* The appearance may differ from your actual screen, depending on your configuration and option settings.
* A maximum of 42 icons can be displayed on products with the fax function installed. A maximum of 16 icons can be
displayed for installed applications.
No. Item Description
1 Message Displays the message depending on the status.
2 Desktop Displays a maximum of 40 function icons
*
including the functions
registered in favorite. Icons that are not displayed on the first page
will appear by changing the page.
3 Screen-switching
keys
Use these buttons to switch between desktop pages.
NOTE
You can also switch views by touching the screen and moving the
finger sideways (i.e. swiping).
4 Taskbar Displays a maximum of 8 task icons.
5 [Logout] Logs out the current user. This is displayed when user login
administration is enabled.
6 Login User Name Displays the logged-in user name. This is displayed when user login
administration is enabled. Selecting "Login User Name" will display
the information of the logged-in user.
7 Status Icon (Wi-Fi) The icon is displayed when Wi-Fi is connected. When Wi-Fi is not
connected, " " is displayed.
8 Status Icon (Error) The icon is displayed during network startup or error.
Select the function.
Home
Admin
Copy
Status/
Job Cancel
10:10
Logout
Send
FAX
Memory
RX Box
Job BoxFAX
Sub
Address
Box
Removable
Memory
Polling Box
Device
Information
Language System
Menu
Favorites
Paper
Settings
1
3
6
5
3
2
4
8
7
Select the function.
Home
Admin
Copy
Status/
Job Cancel
10:10
Logout
Send
FAX
Memory
RX Box
Job BoxFAX
Sub
Address
Box
Removable
Memory
Polling Box
Device
Information
Language System
Menu
Favorites
Paper
Settings
