23
TD-001538-01-A1
Ethernet Device Discoverer
The QSC Ethernet Device Discoverer is a helpful tool used to locate multiple LSS-200’s and other QSC products on a network. For LSS-200’s it also
shows summaries and warning messages if any readings fall out of tolerance within a set number of days. The amount of days to look for out of
tolerance conditions can be set on the main Configuration Page of each individual LSS-200. Since it is able to display multiple devices on a single
page it may be the easiest way to get an overview of an entire multiplex of LSS-200s.
— Figure 22 — Ethernet Device Discoverer Overview
LSS Database Software
The LSS Database (LSS-DB) is designed to provide a collection point for LSS-200 data transmitters and an observation platform for reviewing the
results of the collected data.
Remote LSS-200 devices that have been installed in theaters will post the results of each test to a URL (Uniform Resource Locator) where the LSS-
DB collects the data. The LSS Database provides a mechanism to collect the LSS-200 data and store it in a database. This operation is performed
automatically and requires no intervention by the end user.
Visit the following URL for download and more info: http://ftp.uslinc.com/?dir=ftp/Products/LSS-DB
— Figure 23 — LSS Database Overview
Server
LSS LSSLSS LSS
Remote User Remote User
Theater Router
Internet or Private Network
Apache Server
SQL Server
LSS DB
Corporate
E-mail
Server
Remote
User
Remote
User
