184050 Page 28
Appendix A – Connector Pinouts
Connector Pin Outs
For convenience, all connector pinouts are located in this appendix.
DB25F AES/EBU Input.
The JSD-60 uses the Dolby DMA8 standard pin out for the multi-channel AES digital audio input.
Cable should be twisted pairs with individual shields and 110 ohm characteristic impedance.
Signals Listed By Channels
Audio
Channels
AES/EBU
Pair
JSD-60 Pin out ( +, -,
shield )
Speakers
1, 2
1
14, 2, 1
L, R
3, 4
2
3, 16, 15
C, LFE
5, 6
3
17, 5, 4
Ls, Rs
7, 8 4 6, 19, 18
(Lc/Rc), (Lrs/Rrs),
(HI/VI-N)
Signals Listed By Connector Pins
DB25F
Pin
AES/EBU
Signal
Name
Channel Name
1
GND
2
1/2-
Left/Right-
3
3/4+
Center/LFE+
4
GND
5
5/6-
Left Surround/Right Surround -
6
7/8+
Lc/Rc+ , Lrs/Rrs+ , HI/VI-N
7
GND
8
9
GND
10
11
12
GND
13
14
1/2+
Left/Right+
15
GND
16
3/4-
Center/LFE-
17
5/6+
Left Surround/Right Surround+
18
GND
19
7/8-
Lc/Rc- , Lrs/Rrs- , HI/VI-N-
20
GND
