Unox CHEFTOP MIND.Maps CONVEX Handleiding (175 Pagina's)

Handleiding

start

USB key

Trash

HD

Trash

HD

xxxxx.zip

UNOX

DOWNLOAD

start

Trash

HD

zip

clik

UNOXDIR

USB key

UNOXDIR

UNOX

start

USB key

UNOXDIR

2036.bin

FIRMWARE

2035.bin

2035_F.bin

USB key

Trash

HD

FIRMWARE

2036_F.bin

NEW!

PLUS

ONE

start

USB key

UNOXDIR

2036_F.bin

FIRMWARE

2035_F.bin

2035.bin

USB key

Trash

HD

FIRMWARE

2036.bin

PLUS

ONE

ON

FIRMWARE

2

3 4

5

8

2

3

4

forced upgrade procedure

If the regular upgrade procedure does not

work or when you have to replace the

control panel and recover the original

SD card, proceed as follows:

1

Make sure you have the latest

software available saved in the folder

“FIRMWARE” of your USB stick.

2

Rename the software from

2036.bin, 2035.bin or 2045.bin to:

2036_F.bin for PLUS ovens

2035_F.bin for ONE ovens

2045_F.bin for PLUS BIG ovens

If you are replacing the control board follow

steps “3” and “4” otherwise skip t o step “5”.

3

Remove the SD card from OLD

panel.

4

Insert this SD card inside the NEW

control panel.

5 PLUG the USB stick with the

renamed file and then SWITCH ON

the oven by pressing the power button.

6

Turn on the oven and wait until the

forced upgrade is complete.

7

Upgrade the parameters of the model

with the standard procedure above

starting at section “Load the parameter

le procedure” on page 49.

Insert the USB stick into your PC.

3

Unzip th folder just saved on your

desktop.

Open the USB stick, copy the

UNOXDIR folder from the unzipped

file and paste it in the USB.

2

3

4

1

2045.bin

FIRMWARE

2045_F.bin

8 After the forced upgrade the

oven will automatically change the

name of the software file to

2036_.bin or 2035_.bin or 2045_.bin .

Therefore rename the file if you

intend

to use the file in regular procedure:

2036_.bin -> to 2036.bin (PLUS)

2035_.bin -> to 2035.bin (ONE)

2045_.bin -> to 2045.bin (PLUS BIG)

30
