REF.

DESCRIPTION ITEM CODE

I V F

R

@ 100Hz

DCR

A Contactor VE1095A0 30 mA 230 V ~ 50 Hz 2 kΩ 770 Ω

B

Solenoid

valve

VE2377A0

30 mA 230 V ~ 50 Hz 4.7 kΩ 4.3 kΩ

E

Cooling

fan

VN1165A0

130 mA 230 V ~ 50 Hz 1.1 kΩ 626 Ω

F Motor MT1012A0 1.62 240V 60 Hz 30.5

G Contactor

VE1095A0

230 V ~ 50-60 Hz

LEGEND

I Absorbed current from load

V

Load vo

ltage

F Line frequency

r @ 100Hz Measured value resistance @ 100Hz

DCR DC resistance measured value

Input

NAME

INPUT

DESCRIPTION

INPUT TYPE RANGE

RESOLUTION PRECISION

PHYSICAL

INPUT

BRD_

TEMP

Board temperature probe

Analogue NTC

0 – 100°C

(32-212°F)

1°C between

-20 °C and

+80°C (-4F to

176F)

+/- 5 °C

HEART_1

Single point core probe or probe

#1 of multipoint core probe

Analogue PT100

0 – 300°C

(32-572°F)

0.1°C +/- 0.5 °C

√

HEART_2

Probe #2 of multipoint core probe

Analogue PT100

0 – 300°C

(32-572°F)

0.1°C +/- 0.5 °C √

HEART_3

Probe # 3 of multipoint core

probe

Analogue PT100

0 – 300°C

(32-572°F)

0.1°C +/- 0.5 °C

√

HEART_4

Probe # 4 of multipoint core

probe

Analogue PT100

0 – 300°C

(32-572°F)

0.1°C +/- 0.5 °C √

TAC_1

Tachometer group 1 (speed)

Analogue

30 – 10K

RPM

1 RPM +/- 1 RPM

√

TAC_2

Tachometer group 2 (direction)

Analogue

30 – 10K

RPM

1 RPM +/- 1 RPM

√

IAC_MOT Motors AC current absorbed

Analogue

0 - 8 A

RMS

1 mA

RMS

+/- 50

mA

RMS

VDC Direct voltage on bus

Analogue

0 – 15 V 1 mV +/- 20mV

IDC Direct current

Analogue

0 – 7 A 1 mA +/- 5mA

AC_FREQ

Frequency of voltage line Analogue

0 - 50 - 60

Hz

- -

MOTDIR

Sense of rotation (from TAC1-

TAC2)

Digital - - -

CP_1

Digital input voltage free contact

# 1

Digital - - -

√

CP_2

Digital input voltage free contact

# 2

Digital - - -

√

ALL_TM Thermal protection alarm Digital - - -

ALL_VAC Line voltage presence Digital - - -

26
