Je bekijkt pagina 14 van 85
14
GB/IE/NI
z Check the charge level of the power bank with compressor
Switch on the power bank with compressor
1
by using the switch for the power bank
9
.
When charging, the bars on the battery level indicator
13
will flash.
The number of permanently lit bars on the battery level indicator
13
shows the charge level of the
power bank with compressor
1
.
If the device is fully charged, all four bars will be permanently lit on the battery level indicator
13
.
Bars for the battery level indicator Charge level
1 flashes 0%
1 permanently lit 25%
2 permanently lit 50%
3 permanently lit 75%
4 permanently lit 100%
z Charging the power bank with compressor
Connect the USB cable
24
with the 5 V /2 A charging port (USB-C)
10
and an appropriate USB-A
socket or an appropriate USB network adapter (working output voltage U
out,max
5 V ).
PLEASE NOTE: USB AC adapter not included in the scope of delivery.
PLEASE NOTE: An undervoltage protection circuit is installed in the power bank with compressor
1
to protect the device from damage. This prevents a deep discharge of the power bank with
compressor
1
and automatically switches the device off once the rechargeable battery pack is
fully discharged. In this case, only one of the four bars on the battery level indicator
13
will flash.
No more energy can be obtained and the compressor function will be deactivated.
Please recharge the power bank with compressor
1
.
z Charging mobile phones and tablets
Press the power switch for the power bank with compressor
9
once.
Connect a suitable USB charging cable to the USB port (5 V /2 A)
11
or the USB port
(5 V /1 A)
12
and then plug it into your mobile phone or tablet.
The charging process starts automatically.
PLEASE NOTE: You cannot charge USB devices (e.g. mobile phone, tablet) while the power
bank with compressor itself
1
is being charged.
z Using the integrated compressor
Screw the compressed air hose
17
on to the hose connection
15
of the power bank with compressor
1
(see Fig. C).
Place the device on a level and non-flammable surface. Do not operate the device in a dusty
environment. This is a fire risk and the device could be damaged.
PLEASE NOTE: Depending on the inflatable item, you can either use the compressed air hose
17
directly or use it together with the valve adapters
21
,
22
and
23
supplied in the scope of delivery.
