Ulsonix AIRCLEAN 7G handleiding
Handleiding
Je bekijkt pagina 7 van 43
22.05.2024
1312
EN EN
1. Handle
2. A light informing that the device is operating
3. Ozone control knob
4. Time set knob
5. Air lter cover
6. Power socket and fuse socket
7. Air lter
8. Power cord
9. ON/OFF button
m) It is forbidden to interfere with the structure of
the device in order to change its parameters or
construction.
n) Keep the device away from sources of re and heat.
o) Do not overload the device.
p) Persons with impaired sense of smell must not use
the device.
q) Provide enough free space around the device before
turning it on. Do not obstruct the ozone vent holes.
r) It is strictly forbidden to directly inhale ozone coming
out of the outlet holes of the device. Inhalation of
high concentrations of ozone over a short period
as well as inhalation of low concentrations of ozone
over a long period of time may cause serious risk to
health or life!
ATTENTION! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there
is still a slight risk of accident or injury when using
the device. Stay alert and use common sense when
using the device.
3. USE GUIDELINES
Ozone generator produces ozone from surrounding air.
The user is liable for any damage resulting from
unintended use of the device.
3.1. DEVICE DESCRIPTION
AIRCLEAN 10G | AIRCLEAN 7G | AIRCLEAN 20G |
AIRCLEAN 15G
1. air outlet
2. control panel buttons:
On/O – main on/o switch
Auto – auto mode operation
Timer – timer mode operation
Set – access to parameter setting mode
Up – increasing parameter values
Down – decreasing parameter values
3. display
4. remote control – description of buttons: same as
control panel buttons
5. lter
6. fuse socket
1. air outlet
2. operation indicator lamp
3. operation time selector knob
4. fuse socket
5. air lter
AIRCLEAN 7G
-
WL | AIRCLEAN 10G
-
WL
1. Air outlet
2. Operation indicator lamp
3. Operation time selector knob
4. power cord connection
5. air lter
AIRCLEAN 10G
-
ECO
1
2
3
4
5
5
4
1
2
3
2
1
5
6
3
4
4 3
1
2
7
6
8
5
9
3.3. DEVICE USE
NOTE! Do not exceed the “Recommended operation
duration” as indicated in the above tables. Max. continuous
working time and break time for the ozone generators is:
12 hours of work / 12 hours of break.
NOTE! The device operator takes responsibility for safety
measures and operation of the device.
AIRCLEAN 10G | AIRCLEAN 7G | AIRCLEAN 20G |
AIRCLEAN 15G
• Continuous operation mode: activate ozone
treatment with ON/O button. The display will show
“HOLD ON”. The device will operate continuously.
Model Recommended operation duration /
treated airspace [m
3
] in “Auto” mode
P1 P2 P3
10 minute
operation /
20 minute
pause
20 minute
operation /
20 minute
pause
40 minute
operation /
20 minute
pause
AIRCLEAN 7G <100 100–150 150–200
AIRCLEAN 10G <140 140–210 210–280
AIRCLEAN 15G <210 210–315 315–420
AIRCLEAN 20G <280 280–420 420–560
Model Recommended operation duration /
treated airspace [m
3
]
50 100 150 200 300
AIRCLEAN
7G-ECO
10 min 20 min 30 min 40 min 60 min
AIRCLEAN
20G-ECO
4 min 8 min 12 min 15 min 25 min
AIRCLEAN
5G-WL
20 min 40 min 60 min 80 min 100 min
AIRCLEAN
7G-WL
10 min 20 min 30 min 40 min 60 min
AIRCLEAN
10G-WL
8 min 16 min 24 min 32 min 48 min
Model Recommended operation duration /
treated airspace [m
3
]
50m
3
100m
3
150m
3
200m
3
300m
3
AIRCLEAN
10G-ECO
8 min 16 min 24 min 32 min 48 min
Reactivity of Ozone: Ozone is a highly reactive gas.
It can react with various substances and materials.
Avoid contact with ammable materials, fuels, and
reactive chemicals.
Danger of Reaction Products: Ozone reactions can
produce potentially harmful by-products. Some of
these by-products can be highly reactive or toxic. To
minimize risks, ensure proper ventilation to dissipate
by-products.
Explosiveness of Ozone: Ozone gas is not inherently
explosive, but it can react with certain substances to
form explosive mixtures. Avoid mixing ozone with
substances that can lead to explosive reactions.
Timers and Automation: Use timers or automation
features to control the duration of ozone generation.
Set treatment times according to room size and
ozone concentration guidelines.
Safety Gear: When entering ozone-treated areas,
wear appropriate personal protective equipment
(PPE) such as full masks, gloves, and eye protection
to minimize exposure to ozone and its by-products.
ATTENTION! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there is
still a slight risk of accident or injury when using the
device. Stay alert and use common sense when using
the device.
When operating an ozone generator and if it's absolutely
necessary to be in its vicinity, the type and protection level
of Personal Protective Equipment (PPE) required.
a) Respiratory Protection
• Air-Purifying Respirators: Utilize a respirator
equipped with lters suitable for ozone. In the EU,
lters are classied as P1, P2, or P3, with P3 oering
the highest level of protection against particles.
For protection against gases and vapors such as
ozone, the lter should be combined with a gas lter
classied according to the type of gas it protects
against (e.g., A, B, E, K). Specically for ozone, you
should use an ABEK lter that can protect against
organic and inorganic gases, sulphur dioxide,
ammonia, and its derivatives. Depending on the
concentration of ozone, a half-mask with an ABEK-P3
lter might be sucient for lower concentrations,
while higher concentrations would necessitate a full-
face mask with an ABEK-P3 lter for comprehensive
protection.
• Supplied-Air Respirator (SAR) or Self-Contained
Breathing Apparatus (SCBA): For very high
concentrations of ozone or for long durations, a
more protective approach might be necessary,
such as an SAR or SCBA, which provides clean air
from a source independent of the surrounding
environment.
b) Eye Protection
• Safety Goggles: Closed, air-tight safety goggles
are recommended to protect against eye irritation
caused by ozone exposure. Ensure they form a seal
around the eyes.
c) Skin Protection
• Protective Clothing: Wear long sleeves, long pants,
and gloves to minimize skin exposure. Materials that
provide a barrier to gases or are less permeable to
ozone are preferable. Ozone can degrade certain
materials, so it's important to choose protective
clothing that is resistant to oxidation.
d) Other Considerations
• Ensure proper t and training: For respirators, a
proper t test is essential to ensure the eectiveness
of the mask. Users should also be trained on the
correct use and limitations of their PPE.
• Monitor ozone levels: Use ozone detectors to monitor
AIRCLEAN 20G
-
ECO | AIRCLEAN 7G
-
ECO |
AIRCLEAN 5G
-
WL
3.2. PREPARING FOR USE
APPLIANCE LOCATION
The temperature of environment must not be higher than
40 °C and the relative humidity should be less than 85%.
Ensure good ventilation in the room in which the device
is being used. There should be at least 10 cm distance
between each side of the device and the wall or other
objects. The device should always be used when positioned
on an even, stable, clean, reproof and dry surface, and
be out of the reach of children and persons with limited
mental and sensory functions. Position the device such that
you always have access to the power plug. The power cord
connected to the appliance must be properly grounded
and correspond to the technical details on the product
label.
the concentration of ozone in the area to ensure
it does not exceed safe levels as recommended by
health and safety guidelines.
