TVS X User Manual - Rev 0 - As on 23 Dec 2024
22
BRAKE LEVER RH
1. Front brake lever
The right hand side brake lever controls
a hydraulic circuit. While squeezing the
lever, hydraulic circuit operates the
front brake system. The brake lamp
glows on application of front brake.
2. LH brake lever position adjuster
TVS X comes with adjustable brake
levers. There are three positions
provided for you to adjust the lever to
suit your palm size.
To adjust the lever position, rotate the
position adjuster to any of the three
position by aligning the ‘arrow mark (A)’
on the lever to the number provided on
the adjuster.
THROTTLE GRIP
2
1
The vehicle speed is regulated by
manipulating the throttle grip’s (A)
rotation. Twist the grip towards you
to accelerate and increase the vehicle
speed; conversely, twist it away from
you or release it to decelerate and
reduce the vehicle speed.
SWITCH ASSEMBLY RH
The RH side switch assembly is situated
in the handlebar on the right side and
encompasses the following switches.
1. Hazard Switch
Whenever it is necessary to park
TVS X in a hazardous location, press
the hazard switch with power ‘ON’
condition to start simultaneously
flashing of all turn signal lamps.
This makes others aware of your vehicle
presence. Press the switch again to
turn-off the lamps.
2. Park assist switch
Park assist switch activates park assist
mode and allows vehicle to roll forward
or backward in restricted speed thereby
to reduce the effort of parking by
yourself. Refer “PARKING MODE” on
page 40 for detailed parking assist
function.
1
2
3
A
