03 CONTROLS, INDICATORS, CONNECTIONS
19
4K/UHD 12G-Quad Multi View Monitor
REAR
● RS-422 IN/OUT (RJ-45)
- Control the monitor with the software
provided by TVLogic or with the external
UMD equipment.
● AC IN
- Connect the supplied AC power cord.
- AC 100 ~ 240V (50/60Hz)
● DC IN
- Connect the DC power supply.
- LXM-180U/180P/240U/240P: DC 12V ~ 24V
- LXM-320P/550U: Not supported
● SDI-A/B/C/D Input (BNC)
- SDI signal input connector.
- All four SDI inputs support 12G/6G/3G/
HD-SDI signals.
● SDI-A/B/C/D Output (BNC)
- SDI signal loop-out connector.
- All four SDI outputs support 12G/6G/3G/
HD-SDI signals.
* SDI Output is not activated when the
monitor is turned o or in Standby mode.
● HDMI Input
- Input connector for HDMI signal.
● SFP-A/B Input
- Input connector for SFP optical signal.
● REF Input (To be supported)
- Reference Input for genlock
● PROCESSED Out (SDI) (To be supported)
- The LUT applied images or the downscaled
images or the format converted images are
output to this PROCESSED Out port.
* For more information on this port, refer to
"06 Function Details [4] Processed Output"
in page 56.
● LAN
- Control the monitor with a protocol
provided by TVLogic or the TSL 5.0 protocol.
● GPI-IN (RJ-45)
- Control the monitor externally. The desired
functions can be assigned to each pin.
- Functions can be changed in the GPI
section of the OSD menu.
<WARNING!!>
When using the product make sure to ground,
whenever possible, before connecng the
input signal cable in order to prevent any
possible damage to the product or connected
devices. The damage may include signal noise,
malfuncon of main board or display panel.
And the connected devices such as camera or
video source player may also be inuenced
through signal cable. Please check if the AC
power source and the power extender or
power distributor is grounded.
