05 MENU OPERATIONS
33
4K/UHD 12G-Quad Multi View Monitor
[4] GPI
GPI 2/3
LXM-180P
CHANNEL 1
MONITOR ID
UMD CHARACTER
UMD CHAR . COLOR
0
CHANNEL 1
WHITE
OFF
TOP
SMALL
USER CHAR
OFF
OFF
OFF
OFF
0
UMD DISPLAY
UMD POSITION
UMD FONT SIZE
D-UMD TALLY TYPE
TALLY1 COLOR
TALLY2 COLOR
TALLY3 COLOR
TALLY4 COLOR
GROUP ID
● D-UMD TALLY TYPE
- Adjust the various modes of tally operation.
- The operation of sub menus varies depending
on the settings in [UMD DISPLAY]
- [DEFAULT]: Original TVLogic managing
method (VRT)
- [USER COLOR]: The user can set each tally
color.
- [CHARACTER]: Show tally in the letter color.
The operation is the same as [DEFAULT].
- [BG. COLOR]: Show tally in the letter
background color.
The operation is the same as [DEFAULT].
- [USER TALLY]: This mode receives the signal
fed as bit0 and bit1 of TSL Protocol control
byte, adjusts the color the user wants, and
then shows the tally.
Selectable mode: [O], [White], [Red],
[Green], [Blue], [Yellow], [Cyan]
- [USER CHAR]: Show tally in letter color.
The method is the same as [USER TALLY].
- [USER BG.]: Show tally in letter background
color.
The method is the same as [USER TALLY].
TALLY1 COLOR ~ TALLY4 COLOR
-
This menu sets the color of the input condition
for byte0, byte1 in TSL Protocol Control Byte.
- Selectable color:
[O], [White], [Red], [Green],
[Blue], [Yellow], [Cyan]
● GROUP ID
- Used for grouping the monitors and
controlling the monitors by group when
you control the monitors with the protocol
provided by TVLogic, using RS-422/485
communication or Network.
- Selectable value: [0] to [16]
● UMD FONT SIZE
- Adjust the size of UMD character font.
- Selectable mode: [SMALL], [NORMAL],
[LARGE]
