05 MENU OPERATIONS
32
4K/UHD 12G-Quad Multi View Monitor
[4] GPI
GPI 2/3
LXM-180P
CHANNEL 1
MONITOR ID
UMD CHARACTER
UMD CHAR . COLOR
0
CHANNEL 1
WHITE
OFF
TOP
SMALL
USER CHAR
OFF
OFF
OFF
OFF
0
UMD DISPLAY
UMD POSITION
UMD FONT SIZE
D-UMD TALLY TYPE
TALLY1 COLOR
TALLY2 COLOR
TALLY3 COLOR
TALLY4 COLOR
GROUP ID
- [D-UMD(TSL5 S-16C)]*: Display the 16
characters and the tally signal which are
input by TSL protocol V5.0.
- [D-UMD(TSL5 D-8C)]*: Display a pair of 8
characters and a pair of the tally signals
which are input by TSL protocol V5.0.
- [Ember
+
]*: Display the characters and tally
signals based on Ember
+
protocol.
(* Dynamic UMD functions:
To be supported )
Note
- In Multi-View mode and Picture-by-Picture
mode, [UMD], [ANC], [D-UMD(TSL3 S-8C)],
[D-UMD(TSL5 S-8C)] modes are only
activated.
● UMD POSITION
- Set the display position of the UMD.
- Selectable mode: [TOP], [BOTTOM]
● UMD BG. TRANS
(UMD Background Transparency)
- Adjust the transparency of the UMD
background.
- [OPAQUE]: The background becomes black.
The displayed image is covered by the UMD
background.
- [TRANS]: The background becomes
translucent.
The displayed image is translucently
displayed behind the UMD background.
- [SCALE DOWN]:
● UMD DISPLAY
- Set the UMD mode.
- [UMD]: Display the 8 characters which the
user set in [UMD CHARACTER] menu.
- [ANC]: Display the characters embedded in
SDI signal.
-
[D-UMD(TSL3 S-8C)]*: Display the 8 characters
and the tally signal which are input by TSL
protocol V3.1.
- [D-UMD(TSL3 S-16C)]*: Display the 16
characters and the tally signal which are
input by TSL protocol V3.1.
- [D-UMD(TSL3 D-8C)]*: Display a pair of 8
characters and a pair of the tally signals
which are input by TSL protocol V3.1.
- [D-UMD(TSL5 S-8C)]*: Display the 8 characters
and the tally signal which are input by TSL
protocol V5.0.
