05 MENU OPERATIONS
27
4K/UHD 12G-Quad Multi View Monitor
[2] VIDEO & DISPLAY
Video & Display
FAST MODE
3G FORMAT
TIME CODE ENABLE
BLUE ONLY
H/V DELAY
H/V FLIP
QUAD MODE
LXM-180P
OFF
NORMAL
OFF
OFF
OFF
OFF
SQD
Closed Caption
CLOSED CAPTION
CC INFO
DECODE CHANNEL (608)
CAPTION SERVICE (708)
TELETEXT PAGE
608(ANC)
CC 1
Service 1
800
● CLOSED CAPTION (To be supported)
- Set the closed caption function.
- Selectable mode: [OFF], [608(ANC)],
[608(Line21)], [708], [OP47]
● H/V FLIP
- Flip the displayed image horizontally and/
or vertically.
- [H-FLIP]: The input video is ipped horizontally.
- [V-FLIP]: The input video is ipped vertically.
- [HV-FLIP]: The input video is ipped
horizontally and vertically.
● QUAD MODE
- Set the image division of the SDI dual-link or
quad-link 4K/UHD input signal.
- [SQD]: Select to receive the images of the
quad-link square division system.
- [2SI]: Select to receive the images of the
dual-link or quad-link 2-sample interleave
system.
Note
- The Closed Captions which meet 608:
CEA-608-B, 708: CEA-708-C, OP47
standard are only displayed on the screen.
- Closed Caption is available only when the
input signal is the HD-SDI single link.
● CC INFO (CLOSED CAPTION INFO)
- Displays the Closed Caption information
which the monitor currently receives.
● DECODE CHANNEL (608)
- Set the channel of Closed Caption 608.
- Selectable mode: [CC 1], [CC 2], [CC 3], [CC4]
● CAPTION SERVICE (708)
- Set the service of Closed Caption 708.
- Selectable mode: [Service 1] to [Service 6]
● TELETEXT PAGE
- Set the page of OP47.
- Selectable range: [801] to [8FF]
