MNL- C2-6204-V3.00 37
This menu item allows the adjustment of the serial baud rate used for RS-232 communications. The rate
can be adjusted to 9600, 19200, 28800, 33600, 38800, 57600 and 115200. (This adjustment is provided for
those instances where you wish to use the RS-232 control system for your own purposes.) The default
baud rate is 57600.
The screen labeled ‘Buzzer’ is actually the control for turning the “Beep” “On” or “Off”. Normally this is left
in the “On” position to provide positive feedback that your data entries and parameter changes have been
accepted.
This menu item changes the function of an attached CC-300 CORIOconsole unit. When set to ‘On’ any
‘Take’ will result in the A & B windows (‘buses’) being swapped at the end of the Take – so that another
‘Take’ will put them back to as they were before. (Note that not all units support the CC-300.)
This screen is an informational screen showing the total number of the defined resolutions in the
resolution database. Future firmware releases may increase the total number of resolutions defined in
the database.
If your units supports Logos or Still Images / Testcards then this screen will display how many are present in
the memory of the units.
Power Cycles refers to how many times the unit has been powered since it left the factory. This is an
informational screen. No action is taken regardless of the value shown here, however some users have an
equipment cleaning or specification audit procedure and this information may be useful to those users.
Indicates the total number of times the firmware has been changed over the life of the unit. It is quite
possible for this to be more than 1, as a unit undergoes numerous tests during production.
System
RS232 baud rate [57600]
System
Buzzer [ On]
System
Resolutions 88
System
Power cycles 41
System
Hours in Use 877
System
Logos / T-cards 1 / 4
System
CC-300 A/B bus mode [ Off]
System
Firmware updates 11
