Bungee Pulley

..........................................................................................................................................................

Reattaching the Rower Belt

Begin reattaching the Rower Belt by threading around the Rower Belt

Pulley with the Velcro side facing upward as illustrated.

STEP 1

Next, thread the Belt around the Idle Wheel as shown. Once around

the Idle Wheel, attach the Rower Belt to the Belt/Bungee Pulley.

There is an obvious “lip” at the attachment point.

STEP 2

Wind the Rower Belt onto the Belt/Bungee Pulley until the Rower

Handle is as it’s furthest forward position.

STEP 3

Rethread the Bungee Shock Cord (on opposite side of the Idle Wheel)

back through the Bungee Pulleys and tie o at the Attachment Point.

STEP 4

If Bungee Shock Cords previous tension seemed correct (a good way

to judge is

if the Handle can make it to the furthest point forward on the top of

the Main Frame under Bungee tension alone) then simply tie o at

previous position. If the return is too slack, experiment by tightening

the tension in small increments and testing until the correct tension is

achieved. If the Handle cannot reach the end of the seat rail during a

rowing stroke, then the Bungee Shock Cord is over-tensioned.

STEP 5

Bungee Shock Cord

Rower Handle

Belt/Bungee Pulley

Idle Wheel

Velcro Facing Upward

Hint

Detaching the Strength Machine Belt

Bungee Shock Cord

Bungee Attachment Point

1.To detach Belt, simply pull beyond the range of the normal rowing

stroke until the Belt detaches from the Belt Bungee Pulley.

Tip: You’ll hear the Velcro separating just before the Belt detaches.

2.Cut plastic tie holding Bungee at the Bungee Attachment Point,

pull the Cord through all three pulleys and leave excess on top of

the Tank for now.

..........................................................................................................................................................
