8
« »Never dispose of batteries in water.
«Read this instruction before switching on the
power supply and starting the work.»
« »Never dispose of batteries in fire.
«
»
Protect the battery against heat, e. g., against
continuous intense sunlight.
« »For indoor use only.
depths and remove the drill from the borehole from time to time to humidity, dust penetration and small objects; remember to protect its
remove borings from the borehole.
ventilation openings. Small objects after getting into the casing can
2. To drill large diameter boreholes it is recommended to start with
result in damage to the motor.
drilling a low-diameter borehole and then expand it to the desired
If the battery is removed for transport or storage, make sure the contacts
diameter. It prevents the tool from overloads.
will not short circuit. Remove metal items such as screws, nails, clasps,
3. When the drilling bit is seized during working switch immediately
loose bits, wires, or metal filings from the case or transport container or
tool off to prevent it from being damaged. Switch the rotations
otherwise prevent them from touching the battery.
direction to the anticlockwise rotations and then remove the drilling
MANUFACTURER:
bit from the borehole.
PROFIX Co.Ltd.,
4. Keep the drill aligned with the axis of the borehole. The drilling bit
must be positioned perpendicularly to the surface of the machined
34 Marywilska Street,
material. When the perpendicularity fails to be maintained the
03-228 Warsaw, POLAND.
drilling bit may be seized or broken or, under extreme circumstances,
This appliance is in conformity with national and European standards as
the operator may be injured.
well as with general safety guidelines.
Rotation speed of the drill spindle is controlled by the force the power
NOTE: In case of technical issues, contact an authorised technical service.
switch is depressed with.
Any repairs are allowed to be carried out exclusively by qualified staff with
n Driving screws
use of original spare parts.
It is recommended to drill the pilot borehole first. The pilot borehole must
PICTOGRAMS:
be a little deeper and with a less diameter than the outer diameter of the
screw thread. When the screw is to be driven within the vicinity of the
Explanation of the icons located on the nominal plate and the
material edge the pilot borehole prevents from undesired chipping of the
information tags:
material.
If the screw is driven with abnormal difficulty the screw must be retracted
and the pilot borehole diameter should be enlarged.
Anyway, when problem to drive the screw in persists (e.g. in case of hard
wood grades) try to use a lubricating agent (e.g. liquid soap). Press the
tool to the screw with sufficient force to avoid spontaneous rotation of the
driving bit in the screw head. Use only those bits that accurately match
the bit head. When the screw head is damaged further driving the screw
in or out may prove infeasible.
STORAGE AND MAINTENANCE:
The tool in principle does not require any special maintenance or service.
The tool must be stored in a place that is not accessible to children and
must be kept clean and protected from moisture and dust. The storage
conditions should prevent potential mechanical damage and impact of
the weather conditions.
CAUTION: Remember to always disconnect the battery from the tool prior
PROTECTION OF THE ENVIRONMENT:
to starting the cleaning operations and unplug the charger from the outlet.
NOTE: The symbol nearby denotes that old equipment must
The charger may be cleaned exclusively with use of a dry cloth. Use also a
never be thrown away together with other waste (with the
clean cloth to clean regularly the ventilation openings of the tool to keep
penalty of a fine). Hazardous components of electronic
them patent. From time to time disassemble the grip and remove dust
equipment may adversely affect the natural environment and
and other rubbish from the interior.
human health.
The tool housing must be cleaned with use of a moistened cloth small
Each household may contribute to the recovery and reuse (recycling) of
quantity of soap and then wiped dry. Do not use any detergents or
old machinery and equipment. Both in Poland and Europe a system for
solvents as they can damage parts made from plastics. After cleaning let
recovery of used equipment either exists or is being created. The system
the tool dry completely before it is used again.
obliges all organizations that sell such equipment to collect the used
machinery and appliances. Moreover, general purpose collecting points
TRANSPORTATION:
Store and transport the tool in its transport box to protect it against
for such equipment are available.
