REFRIGERATED FOOD PREP truemfg.com
TEC_TM_090 | REV. F | EN
P#975530
01/14/2025 Page 30 of 44
Maintenance & Servicing (cont.)
Required Tools
Required tools include (but may not be limited to) the following:
• Phillips screwdriver or bit driver
• 1/4" nut driver
• 3/8" nut driver
• Stiff bristle brush
• Tank of compressed air
• Vacuum cleaner
• Flashlight
• Eye protection
• Gloves
Procedure
1. Unplug the unit or remove the power supply.
2. Access the condenser coil.
TPP & TUC/TWT-44/67/93
Open the grill assembly door. See fig. 1.
TFP/TFT/TSSU/TUC/TWT
Remove the rear cover (see fig. 2). Screw locations will vary by
model.
3. With a stiff bristle brush, carefully clean accumulated dirt from
the front condenser coil fins. See fig. 3.
4. With dirt removed from the surface of the coil, use a flashlight
to verify that you can see through the coil. See fig.4.
If the view is clear, carefully vacuum any dirt around or behind
the condensing unit area. Then reinstall the cover (if so
equipped), restore power, and verify operation.
If the view is still blocked with dirt, for TPP and TUC/TWT-
44/67/93 units proceed to step 5. For all other units proceed to
step 7.
5. Remove the condenser base bolts. See fig. 5.
6. Carefully slide the condensing unit out (tubing connections are
flexible).
7. Gently blow compressed air or CO₂ through the coil until it is
clean.
8. Carefully vacuum any dirt around and behind the condensing
appliance area.
9. Carefully slide the compressor assembly back into postion and
reinstall the bolts.
10. Reinstall the rear cover (if so equipped), connect power to the
unit, and verify correct operation.
Condenser Coil Cleaning
DANGER!
Risk of electric shock or burn!
• Unplug the appliance or disconnect power before
installation or servicing.
• DO NOT clean appliance with a pressure washer
or hose.
WARNING!
The appliance owner is responsible for performing
a Personal Protective Equipment (PPE) Hazard
Assessment and ensuring adequate protection
during maintenance and cleaning procedures.
Use appropriate tools, safety equipment, and PPE
during installation and servicing.
Sharp edges! Coil fins are sharp and metal
components can have sharp edges. Take care
when moving, installing, cleaning, servicing, and
maintaining the appliance to avoid cuts.
Risk of eye injury! Airborne dust and debris can
cause eye injury. Eye protection recommended.
USER ACTION!
DO NOT place any filter material in front of the
condenser coil.
NOTICE!
The cleaning of the condenser coil is not covered
by warranty!
