2. If the LED does not light up when the plug is connected and the vacuum cleaner does not
work, the fuse in the plug may burn out. If this is the case, replace it with a new one. To do
this, unscrew the mounting ring, remove the plug contact and the fuse. Install in reverse order
(IX).
Caution! If suspicious vibrations, a drop in thrust force or noisier motor operation are
observed during operation, this may mean that the tank is full or that the exible hose
or suction attachment is clogged. In this case, turn off the vacuum cleaner immediate-
ly with the switch and unplug the power cord from the mains socket. Then empty the
tank and check the permeability of the exible hose and attachment. Restore patency
if necessary. If it is not possible to restore patency of the exible hose or the suction
attachment, replace them with new ones before continuing to work.
Maintenance of the vacuum cleaner
Caution! Before carrying out any maintenance work, make sure that the power cord plug
has been disconnected from the mains socket of the power system.
1. After each use of the vacuum cleaner, check the tank, lid seal and air lter as described in the
section.
2. Clean the vacuum cleaner from the outside and the lter with a stream of compressed air
of not more than 0,3 MPa. Special attention should be paid to the permeability of ventilation
openings, both inlet and outlet openings. Clean them with a stream of compressed air of not
more than 0,3 MPa, if needed. Do not use sharp, metal objects for cleaning the ventilation
openings. Do not immerse the vacuum cleaner in water to clean it. Check the vacuum cleaner
hose for damage after and before each use. It is forbidden to use a damaged hose.
3. Remove larger dirt from the housing with a soft cloth.
Technical specication
Power supply voltage [V] 12 d.c.
Rated power [W] 100
Hose length [cm] 39
Protection class III
Weight [kg] 0,9
Fuse 6 x 30 mm, 15 A / 250 V, BGDP
Instruction manual
11
EN
Tracer OK-V1
