DeltaStream Pizzabox Optical Line Terminal

9Introduction

For DS-P7500-08

LED Indication

PWR

On: The device is powered on.

Off: The device is powered off or power supply is abnormal.

Flashing: Power supply is abnormal.

SYS

On: The device works properly.

Off: The device works improperly.

Flashing Slowly and Then Quickly: The reset button is pressed and held and then

the device is reset to the default settings.

Flashing Normally: The device is upgrading.

Flashing Quickly: There are alarms.

PON

Green On: An ONU is linked to the corresponding port.

Green Flashing: An ONU is linked to the corresponding port and transmitting or

receiving data.

Off: No device is linked to the corresponding port.

SFP+

Green On: Running at 10 Gbps, but no activity.

Green Flashing: Running at 10 Gbps and transmitting or receiving data.

Yellow On: Running at 1 Gbps, but no activity.

Yellow Flashing: Running at 1 Gbps and transmitting or receiving data.

Off: No device is linked to the corresponding port.

QSFP+

Green On: All 4 individual channels of the QSFP+ are running at 10 Gbps, but no

activity.

Green Flashing: All 4 individual channels of the QSFP+ are running at 10 Gbps, and

transmitting or receiving data.

Yellow On: At least 1 individual channel has not running at 10 Gbps, but no activity.

Yellow Flashing: At least 1 individual channel has not running at 10 Gbps, and

transmitting or receiving data.

Off: No device is linked to the corresponding port.

MGMT

Green On: Running at 1 Gbps, but no activity.

Green Flashing: Running at 1 Gbps and transmitting or receiving data.

Yellow On: Running at 10/100 Mbps, but no activity.

Yellow Flashing: Running at 10/100 Mbps and transmitting or receiving data.

Off: No device is linked to the corresponding port.
