INSTALLATION
Warning!
Drain Hose
•
• Position drain hose properly, otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Trough
Hose Retainer
Bin
d
Max.100cm
Min.60cm
Min.60cm
Max.100cm
If the machine has
• drain hose support, please install it like the following .
Warning!
Note!
Water inlet hose
Water inlet valve
Connect the other end of water inlet hose to the inlet valve at the backside of
product and fasten the hose tightly clockwise.
15
Min. 60cm
Max
. 100cm
Drain port
Do not
the screw
unscrew
Drain port
Min. 60cm
Max
. 100cm
There are two ways to place the end of drain hose:
1. Put it into the drain port. If the drain hose is put
into the drain hole on the floor, fix the drain hose
on the back of the appliance to prevent water
overflow from the drum.
2. Connect it to the branch
the trough.drain hose of
•
• If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.
When installing drain hose, fix it properly with a rope.
