INSTALLATION
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Connect Water Inlet Hose
Connect the water inlet hose as indicated, There are two ways to connect the
inlet hose.
water
• To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush, modify water inlet hose.or
!
2
3
4
1
Raise
Lower
Lock nut
Foot
Warning!
Warning!
Loosen clamp nut and
four bolts
Press the tap end
tightly to the rubber
ring inside the clamp,
and then, tighten the
4 bolts
Press slide bushing,
insert water inlet
hose into
base
connecting
Slide bushing
2
3
41
Connection finished
Tap with threads and water inlet hose
Special tap for washing machine
Slide bushing
14
1. Connection between ordinary tap and water inlet hose.
2. Connection between screw tap and water inlet hose.
1. Check if the legs are closely attached to the cabinet. If not, please turn them to
their original positions and tighten the nuts.
2. Loosen the lock nut and turn the feet until it closely contacts with the floor.
3. Adjust the legs and lock them with a spanner, make sure the machine is steady.
Clamp nut
5mm
