AdjustingtheReverseDriveBelt
Tension
Ifthemachinedoesnotoperateinreversewhenthe
reversedrive-controlleverisengaged,adjustthejam
nutsonthereversedrivecable1turnatatimeuntil
thereversedrivecontrolfunctionsproperly.
Note:Ifthemachinedoesnotoperateinreverse
andyoucannotadjustthejamnutsfurther,replace
thebelt.
ReplacingtheBelts
ServiceInterval:Every50hours
RemovingtheBelts
1.Parkthemachineonalevelsurface,shutoff
theengine,andwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
2.Removethesparkplugwire.
3.Shiftthedrive-modelevertotheNEUTRAL
position.
4.Removethewheels,upperpulleyshrouds,and
lowerpulleyguards.
g357906
Figure33
5.Detachtheforwardandreversedrivecables
fromthedrivecontrollevers.
6.Pullthereversearmawayfromtheengine
pulley.Use2wrenches(13mm)toloosenthe
idlerpulleyonthearmsothatyoucanremove
thereversedrivebelt.
g356686
Figure34
1.Reversearm3.Wirebeltguide
2.Idlerpulley4.Reversedrivebelt
7.Gentlyrotatethetransmissionpulleyandforce
theforwarddrivebeltoutofthegrooveand
awayfromthepulley.
g356685
Figure35
23
